TP-Link 5GHz 300Mbps 23dBi Outdoor CPE – CPE610

The TP-Link 5GHz 300Mbps 23dBi Outdoor CPE – CPE610 is a high-performance outdoor CPE engineered for extremely long-range, high-speed wireless connectivity in the 5 GHz band. Featuring a powerful 23 dBi directional antenna and 300 Mbps 802.11a/n throughput, it is optimized for point-to-point (PtP) and point-to-multipoint (PtMP) applications over distances of up to 30 km.

Built for reliability in harsh environments, it comes with a weatherproof housing, advanced surge protection, and Pharos MAXtream TDMA technology to ensure stable connections even in congested wireless scenarios.

Detailed Specifications

Wireless Standards:

• IEEE 802.11a/n

Frequency Band:

• 5.150–5.875 GHz (varies by country/region)

Wireless Speed:

• Up to 300 Mbps (802.11n, 40 MHz channel width)

Antenna:

• Integrated 23 dBi 2×2 MIMO directional dish antenna
• Beamwidth: 9° (horizontal & vertical) for ultra-focused long-range links

Transmit Power:

• Adjustable up to 27 dBm (500 mW)

Range Performance:

• Point-to-point: up to 30 km (clear line-of-sight)
• Point-to-multipoint: extended range with optimal deployment

Processor & Memory:

• Qualcomm Atheros Enterprise 560 MHz CPU
• 64 MB DDR2 RAM, 8 MB Flash

Operation Modes:

• Access Point (AP)
• Client (AP Client/Station)
• Repeater
• AP Router (WISP)
• Bridge

Ethernet Port:

• 1× 10/100 Mbps Shielded Ethernet Port (Passive PoE in)

PoE Power Supply:

• Passive PoE adapter included (up to 60 meters)
• Power: 16–27V DC via PoE

Management & Software Features:

• Pharos Control centralized management platform
• Pharos MAXtream TDMA technology for improved multi-user performance
• QoS for traffic prioritization
• VLAN support
• Watchdog for automatic system recovery

Security:

• WPA/WPA2-PSK and WPA/WPA2-Enterprise encryption
• Wireless MAC filtering
• Access control lists

Enclosure & Durability:

• Outdoor weatherproof housing (IPX5-rated)
• Operating temperature: -30°C to 70°C
• Built-in 15 kV ESD and 6 kV lightning protection

Dimensions & Weight:

• 280 × 280 × 184 mm
• Weight: ~1.9 kg

Key Features

• Ultra-long-range 5 GHz wireless connectivity up to 30 km
• Powerful 23 dBi directional antenna for focused and stable links
• 300 Mbps 802.11a/n performance with 2×2 MIMO
• Weatherproof IPX5 design with advanced lightning and ESD protection
• Passive PoE for flexible installation up to 60 m
• Centralized management via Pharos Control software

Meta Description

TP-Link 5GHz 300Mbps 23dBi Outdoor CPE – CPE610, PoE support, and IPX5 weatherproof design. Ideal for ultra-long-range Wi-Fi, WISP, and surveillance links.
