MikroTik netPower Lite 7R (CSS610‑1Gi‑7R‑2S+OUT) Switch

Outdoor-rated MikroTik netPower Lite 7R (CSS610‑1Gi‑7R‑2S+OUT) smart switch with 8× Gigabit (7 reverse‑PoE‑in), 2× 10G SFP+, 28 Gbps throughput, rugged IP54 housing, and versatile power options.

Here are the detailed specifications for the MikroTik CSS610‑1Gi‑7R‑2S+OUT (netPower Lite 7R):

⚙️ General & Hardware

• Product Code: CSS610‑1Gi‑7R‑2S+OUT (netPower Lite 7R)
• Switch Chip: Marvell 88E6193X
• Storage: 64 KB flash (SwitchOS Lite)
• MTBF: ~200,000 hours @ 25 °C
• Dimensions: 304 × 212 × 71 mm
• Operating Temperature: –40 °C to +70 °C
• Certifications: CE, EAC, RoHS; Ingress Protection: IP54 (weatherproof)

🔌 Connectivity

• Ethernet Ports: 8 × 10/100/1000 Mbps (RJ45)
  • 7 × reverse PoE-in (draws power from client)
  • 1 × PoE-out (Ether8)
• SFP+ Ports: 2 × 10 Gbps fiber uplink

⚡ Power & PoE

• Power Inputs:
  • Passive PoE-in (via 7 ports)
  • DC jack (12–57 V)
  • 2-pin terminal (12–57 V)
• Power Consumption:
  • Idle (no attachments): ~7 W
  • Max (under full load): ~29 W
• PoE-out on Ether8:
  • If input <30 V: up to 600 mA
  • If input >30 V: up to 450 mA

📊 Performance

• Non-blocking throughput: 28 Gbps
• Switching capacity: 56 Gbps
• Packet forwarding: ~41.7 Mpps

🛠 Software & Management

• Operating System: SwitchOS Lite (browser/Web UI)
• Key Features: VLANs, port‑to‑port forwarding, MAC filtering, traffic mirroring, bandwidth control, header rewriting, storm control, passive cooling
• SFP+ uplink management and monitoring

🏗 Physical & Accessories

• Build: Rugged outdoor enclosure, pole/attic-mountable
• Cooling: Passive (fanless)
• Included: K‑66 hose clamps, mounting hardware
• Power Adapter: Not included (must be purchased separately)

✅ Application Summary

Ideal as an outdoor reverse-PoE switch for GPEN/ISP distribution: rugged, multi-source power inputs, 10G uplinks, and seven ports that can receive PoE from client devices.

Datasheet
