Device Type: Sealed Lead-Acid (SLA) UPS Replacement Battery
Part Number/SKU: ELITE-BATTERY-9AH / Mercury Elite 9
Brand: Mercury
Battery Type: Sealed Lead-Acid (SLA) with AGM (Absorbent Glass Mat) Technology
Nominal Voltage: 12V DC
Capacity: 9 Amp-Hours (9Ah) @ 20-Hour Rate
Physical Specifications:- Dimensions (L × W × H): 151 × 65 × 94 mm
- Weight: Approx. 2.48 kg – 2.8 kg
- Terminal Type: Faston Tab (F2) / Nut & Bolt Terminals; Terminal Size: 6.35 mm (0.25 in.)
Charging Specifications:- Float Charging Voltage: 13.5V – 13.8V @ 25°C
- Cyclic Charging Voltage: 14.4V – 15.0V @ 25°C
- Maximum Charging Current: 2.7A
- Charging Time: 4 – 6 Hours (to 90% capacity)
Performance & Reliability:- Design Life: 3 – 5 Years (Depending on Usage & Environment)
- Recharge Cycles: 200 – 300 Cycles (at 50% Depth of Discharge)
- Self-Discharge Rate: Approx. 3% per Month at 25°C
- Maximum Discharge Current: 135A (5 Seconds)
- Shelf Life: Up to 6 Months at 25°C (Recharge if Stored Long-Term)
Environmental:- Discharge Temperature: -20°C to 50°C
- Charge Temperature: 0°C to 40°C
- Storage Temperature: -20°C to 40°C
- Operating Humidity: 5% – 95% RH (Non-Condensing)
Safety & Standards:- Certifications: CE, UL, ISO 9001
- Construction: Non-Spillable, Maintenance-Free, Leak-Proof Design
- Safety Valve: Yes (Pressure Release)
- Fire-Retardant Case: Yes (UL94 HB/V-0 Compliant)
Compatibility: Mercury UPS Models Requiring 12V/9Ah Batteries; Also Compatible with APC, Mecer, Eaton UPS Systems (as a Replacement for BB HR9-12, etc.)
Warranty: 1 Year Replacement Warranty
Key Specs: Mercury Elite 9, 12V 9Ah SLA/AGM UPS Replacement Battery, 151×65×94mm, 2.48kg, F2 Faston Terminals, 3–5 Year Design Life, 200–300 Cycles at 50% DoD, 135A Max Discharge (5s), 13.5–13.8V Float / 14.4–15.0V Cyclic Charging, 2.7A Max Charging Current, 4–6 Hour Recharge, CE/UL/ISO 9001 Certified, Maintenance-Free, Leak-Proof, 1-Year Warranty
Usage: UPS Battery Replacement (Mercury & Compatible Brands), Emergency Lighting Systems, CCTV & Security Systems, Alarm Systems, Small DC-Powered Devices, Home & Office Backup Power
