KSh 399,430(KSh 463,339 Incl VAT)
Device Type: Hot-Swappable Power Module for Modular UPS
Part Number/SKU: NMLU-AC25PM
Brand: Norden (Maxion Series)
Module Rated Power: 25 kW / 25 kVA
Topology: True Online Double-Conversion, Fully Digital Control
Output Power Factor: 1.0 (Unity)
Input Configuration: 3P+N+PE, 380/400/415 VAC (L-L)
Input Power Factor: >0.99
Input THDi: <2% (at 100% linear load)
Input Voltage Range: 304–478 VAC (full load); 304–228 VAC with derating
Input Frequency: 40–70 Hz
Output Voltage: 380/400/415 VAC (L-L)
Output Voltage Accuracy: ±1.0%
Output THD: <1% (linear load); <5% (non-linear load)
Overload Capability: 110% for 1 hour; 125% for 10 min; 150% for 1 min
Efficiency: Up to 96% (Normal & Battery Mode)
Battery Voltage: 480 VDC
Battery Type Support: VRLA & Lithium-Ion
Charging Capacity: 20% × Pout
Display: LED + 10-inch Touch LCD with IoT Functionality
Communication: USB, RS232, RS485, Dry Contact, Cold Start
Cooling: Internal Fan
Protection Rating: IP20
Operating Temperature: 0°C to 40°C
Humidity: 0–95% Non-Condensing
Certifications: IEC 62040-1, IEC 62040-2, IEC 62040-3, IEC 62040-4
Warranty: 2 Years (Manufacturer Standard)
Key Specs: Norden NMLU-AC25PM, 25kW/25kVA Hot-Swappable Power Module, Maxion Series, True Online Double-Conversion, Unity Output Power Factor, 3P+N+PE Input, 380/400/415VAC, Input PF >0.99, THDi <2%, Output THD <1% Linear, Up to 96% Efficiency, 480VDC Battery System, Lithium-Ion Compatible, 10-inch Touch LCD with IoT, USB/RS232/RS485/Dry Contact, IP20, IEC 62040 Certified
Usage: Data Centers, IT Infrastructures, Telecom Networks, Industrial & Commercial Critical Power Applications, Scalable Power Protection with N+X Redundancy
