Device Type: 16-Channel Penta-brid 1080N/720P Compact 1U 1HDD WizSense Digital Video Recorder (XVR)
Brand/Model: Dahua DH-XVR4116HS-I (V2.0)
Video Output: 1× HDMI (up to 1080p), 1× VGA (up to 1080p)
Data Ports: 1× RJ45 10/100 Mbps Ethernet, 1× RS-485 (PTZ control), 2× USB
HDD Support: 1× SATA interface, up to 16 TB (HDD not included)
Analog Input: 16× BNC (HDCVI / AHD / TVI / CVBS auto-detect)
IP Input: Up to 18 channels (2 IP by default + 16 analog convertible); max 6 MP per channel
Incoming Bandwidth: 64 Mbps
AI Features: 8-channel SMD Plus (human/vehicle filtering), AI Coding, Smart H.265+ / H.265
Compression: H.265+ / H.265 / H.264+ / H.264
Audio: 1× RCA Audio In / 1× RCA Audio Out; 16-channel audio over coax
Alarm Linkage: Access controller, IPC external alarm output, email, buzzer
Operating System: Embedded Linux
Key Specs: Dahua DH-XVR4116HS-I (V2.0), 16CH Penta-brid XVR, 1080N/720P Recording, 1× HDD up to 16TB, 18 IP Channels (6MP), 64 Mbps Bandwidth, 8-Ch SMD Plus, AI Coding, H.265+, HDMI/VGA, RS-485
Usage: Small-to-Medium CCTV Systems, Hybrid Analog/IP Upgrades, Retail/Office/Home Surveillance, AI-Assisted Human/Vehicle Detection
