KSh 12,500(KSh 14,500 Incl VAT)
Datasheet
Device Type: Optical Fingerprint Sensor / Reader
Brand/Model: SecuGen Hamster Plus (HSDU03P)
Video Output: N/A (biometric reader; no video interface)
Data Ports: 1× USB 1.1 Full-Speed / USB 2.0 Hi-Speed connection
Sensor & Imaging Specifications:
Sensor Type: Optical, contact-based (SDU03P module) with patented SEIR fingerprint biometric technology
Durability: High-performance, maintenance-free optical sensor resistant to scratches, impact, vibration, and electrostatic shock
Image Resolution: 500 DPI
Image Size: 260 × 300 pixels
Platen Size: 14.6 mm × 17.9 mm (official SecuGen spec); some distributor listings state 16.1 mm × 18.2 mm
Effective Sensing Area: 13.2 mm × 15.2 mm
Image Grayscale: 256 levels (8-bit)
Light Source: Red LED
Capture Speed: 0.2 – 0.5 seconds (with Smart Capture)
Power & Environmental:
Supply Voltage: 5V DC (via USB)
Current Consumption: 140 mA (max.)
Operating Temperature: −20°C to +65°C (official); one source lists 0°C to +40°C
Operating Humidity: 90% RH or less, non-condensing
Physical:
Dimensions (without stand): 27 × 40 × 73 mm
Dimensions (with stand): 53 × 73 × 84 mm
Weight: 100 g (without stand); 165 g (with stand)
Cable Length: 1500 mm
Standards & Compliance:
Biometric Standards: INCITS 378, ISO/IEC 19794-2, ISO/IEC 19794-4
Certifications: FCC, CE, KC, RoHS, WHQL
Supported OS: Windows 11/10, Windows Server (2022/2019/2016/2012/2008 R2), Android 3.1+, Linux
Warranty: 1-Year Limited
Key Features: Auto-On finger detection, Smart Capture (auto-adjusts for dry/wet/scarred fingers), Latent print rejection (rejects prior fingerprints left on sensor), Device Recognition, 360-degree fingerprint rotation, removable weighted stand, integrated finger guide
Key Specs: SecuGen Hamster Plus (HSDU03P), Maintenance-Free Optical Fingerprint Sensor, Scratch/Impact/Vibration/ESD Resistant, 500 DPI, 260×300 px Image, 13.2×15.2 mm Sensing Area, 0.2–0.5s Smart Capture, USB 2.0, 5V/140mA, FCC/CE/RoHS, 1-Year Warranty
Usage: PC/Network Login & Password Replacement, Access Control & Time Attendance, Identity Verification & Authentication, Biometric Application Development (SDK available), Enterprise Security Deployments
