KSh 1,860(KSh 2,158 Incl VAT)
Device Type: 6-Core Security / Alarm Cable (Low Voltage)
Video Output: N/A (Low-voltage signal cable for sensors and control panels)
Data Ports: N/A (Hardwired connection; terminated into alarm panel terminals, detectors, or sensors)
Conductor & Core Specifications:
Core Count: 6 cores
Conductor Size: Common size is 0.22 mm² (24–25 AWG), with conductor specs often listed as 7/0.18mm or 7/0.185mm (7 strands). Some variants offer mixed sizes or larger 1.0mm² conductors.
Conductor Material: Varies by grade, including Bare Copper (99.95% purity), Tinned Copper, TCCA (Tinned Copper Clad Aluminium), and CCA (Copper Clad Aluminium). Bare/tinned copper is preferred for reliability, while CCA is a budget alternative.
Core Colours: Standard colour code for 6-core is typically Red, Blue, Yellow, Black, Green, White. Some variants include Brown instead of one of these colours.
Shielding & Jacket:
Shielding: Available in both Unscreened (for general indoor use) and Screened/Shielded (with aluminium foil/Mylar tape and a copper drain wire) variants to protect against electromagnetic interference (EMI).
Insulation Material: Typically PVC or LSZH (Low Smoke Zero Halogen). LSZH is preferred for fire-safety critical environments.
Jacket Material: Common materials are PVC (standard) and LSZH/LSF (fire-retardant, low-smoke). PE is also used for outdoor variants.
Outer Diameter: Ranges approximately from 4.0 mm to 4.9 mm, depending on insulation, shielding, and jacket material.
Electrical & Environmental Characteristics:
Voltage Rating: Commonly 50V to 300V depending on the standard and application.
Temperature Rating: Typically -20°C to +70°C for standard cables. Fire-rated variants may have higher ratings.
DC Resistance: Varies by conductor size (e.g., ≤ 155 Ω/km for standard copper, or ≤ 95 Ω/km for some 0.22mm² variants).
Fire Rating: Look for standards like CPR Eca (flame retardant) or BS 7629-1 / BS 5839-1 (fire-resistant) for life-safety installations.
Key Specs: 6-Core Alarm Cable, 0.22mm² Conductors (7-strand), Bare/Tinned Copper or CCA/TCCA, Unscreened or Screened (Foil+Drain), PVC or LSZH Jacket, 50V–300V Rated, -20°C to +70°C, CPR Eca / BS Standard Compliant Options
Usage: Intrusion & Burglar Alarm Systems, Fire Detection & Alarm Circuits, Access Control (Door Contacts & Readers), Intercom Systems, Low-Voltage Signal & Control Wiring
