KSh 5,000(KSh 5,800 Incl VAT)
Datasheet
Device Type: Active Infrared (IR) Beam Detector / Photoelectric Perimeter Sensor (30m Outdoor)
Brand/Model: Generic — 30m IR Beam (common models: Optex AX-100TF, Takex PB-30TK, ABUS LS2030, Securi-Prod 30m Dual IR)
Video Output: N/A (Intrusion detection device; relay output, not a video signal)
Data Ports: Alarm Relay Output (NO/NC dry contact); Terminal Block Wiring (Power + Relay)
Detection & Performance:
Detection Method: Infrared beam interruption (dual synchronized beams; alarm triggers only when both beams are broken simultaneously)
Outdoor Detection Range: 30 m (100 ft)
Indoor Detection Range: Typically 60 m (200 ft) (double the outdoor rating)
Beam Arrival Distance (Max.): Up to 300 m (1,000 ft) on some models
Interruption Period: Selectable 50 / 100 / 250 / 500 ms (some models 50–700 ms)
Beam Channels/Frequencies: 4 selectable channels (prevents cross-talk between stacked units)
Light Immunity: Up to 50,000 lux sunlight immunity (auto-gain control)
Alignment: Visual and audible alignment indicator
Electrical & Power:
Operating Voltage: 10–30 V DC (typical); some models 12–24 V DC
Current Consumption: Approx. 65 mA (varies by model)
Alarm Output: Relay contact NC/NO, 1A / 120 V AC (varies)
Power Supply: Not included; requires external DC power at the transmitter and receiver
Physical & Environmental:
Protection Rating: IP55 (weatherproof, dust and water jet resistant); some models IP65
Operating Temperature: −25°C to +55°C (varies by model)
Dimensions (W×H×D): Approx. 74 × 173 × 72 mm (ABUS LS2030) or 170 × 65 × 69.5 mm (Optex AX-100TF)
Weight: Approx. 0.7–0.75 kg per unit
Housing: UV-resistant plastic with anti-frost / anti-fog design
Mounting: Wall or pole mount (brackets typically included)
Key Specs: 30m Outdoor IR Beam Detector, Dual Synchronized Beams, 30m Outdoor / 60m Indoor Range, Selectable 50–500ms Interruption Period, 4 Selectable Channels, 50,000 lux Sunlight Immunity, NC/NO Relay Output, 10–30 V DC, IP55, −25 to +55°C, Visual/Audible Alignment, Anti-Frost Design
Usage: Perimeter Intrusion Detection for Residential & Commercial Properties, Fence-Line & Wall-Top Detection, Gate & Driveway Security, Balcony & Boundary Protection, Beam Stacking for Tall Perimeters (Multiple Beams), Integration with Alarm Panels & Access Control Systems
