Device Type: 2MP Smart Dual Light HDCVI Two-way Talk Fixed-focal Eyeball Camera
Model / SKU: DH-HAC-HDW1200TRQP-IL-T-0280B-DIP (Dahua Lite Series)
Image Sensor: 2MP CMOS
Max Resolution: 1920 × 1080 (1080p) @ 25fps (PAL) / 30fps (NTSC)
Lens: 2.8mm Fixed-Focal, F2.0, M12 Mount
Field of View: H: 111.3°, V: 60.8°, D: 134.2°
Night Vision: Smart Dual Light (IR + Warm Light), Illumination up to 25m
Min. Illumination: 0.01 lux @ F2.0 (Color) / 0.001 lux @ F2.0 (B/W) / 0 lux (Illuminator on)
Video Output: 1x BNC – Switchable CVI / TVI / AHD / CVBS
Audio: Built-in Microphone & Speaker (Two-way Talk via CVI/TVI; pickup up to 8m)
Noise Reduction: 3D NR
WDR: DWDR
Power: 12V DC (±30%); Max 4.62W
Protection: IP67 (Weatherproof)
Operating Temp: -40°C to +60°C
Casing: Plastic
Dimensions / Weight: Φ97.4 × 90.4 mm; 0.17 kg
Key Specs: Dahua DH-HAC-HDW1200TRQP-IL-T-0280B-DIP, 2MP 1080p HDCVI Eyeball Camera, 2.8mm Fixed Lens, Smart Dual Light (IR + Warm Light 25m), Two-way Talk (Built-in Mic & Speaker), 4-in-1 Video Output (CVI/TVI/AHD/CVBS), 3D NR, DWDR, IP67, 12V DC, Plastic Housing
Usage: Outdoor/indoor surveillance for homes, shops, offices, and small businesses; entrances and driveways requiring two-way audio communication; 24/7 monitoring with full-color night vision when warm light activates.
