Dahua DHI-IPMECD-1053-LM35-T42, Straight Arm Barrier Gate (Left), 3.5 m Boom, ~4.2 s, 24V DC Brushless, IP54

Device Type: Parking Boom Barrier Gate (Straight Arm, Left-Direction)
Brand/Model: Dahua DHI-IPMECD-1053-LM35-T42
Video Output: N/A
Data Ports: RS-485 and I/O interfaces for loop, IR, and radar sensor integration; rolling-code wireless remote control
Boom & Performance:
Boom Type: Straight arm, left-side operation
Boom Length: 3.5 m (11.48 ft)
Opening Time: Approximately 4.2 seconds
Drive System: 24V DC brushless motor
Motor Lifespan: Up to 3,000,000 cycles
Spring Lifespan: Up to 800,000 cycles
Power & Protection:
Input Power: 220V AC ±10% (motor driven by 24V DC)
Power Consumption: ≤200W
Protection Rating: IP54
Operating Temperature: −35°C to +65°C
Operating Humidity: Up to 90% RH (non-condensing)
Casing Material: Metal with anti-corrosion coating
Key Features:
Anti-Smash Protection: Auto-lifts boom upon obstruction contact or power failure
Sensor Compatibility: Supports external inductive loops, IR sensors, and radar
Digital Display: Shows operating status and fault codes
Cycle Counter: Tracks open/close cycles
Fleet Mode: One-click continuous open for vehicle convoys
Remote Control: Rolling-code wireless, up to 50 m range
Key Specs: Dahua DHI-IPMECD-1053-LM35-T42, Straight Arm Barrier Gate (Left), 3.5 m Boom, ~4.2 s Opening, 24V DC Brushless Motor, ≤200W, IP54, −35°C to +65°C, Anti-Smash Auto-Lift, Loop/IR/Radar Compatible, 3M Cycle Motor Life, 50 m Rolling-Code Remote
Usage: Parking Lot Entry/Exit Control, Vehicle Access Management, Commercial & Residential Gates, Campus & Industrial Site Access
