Device Type: Handheld Optical Fiber Identifier (Live Fiber Detector)
Brand/Model: Generic — brand varies (e.g., VIAVI FI-10, Jonard OFI-50, Wilcom F6121A, Corning CheckPoint)
Video Output: N/A
Data Ports: N/A (handheld optical detection tool; no data interfaces)
Detection & Performance:- Detection Technique: Non-destructive macro-bend detection (no need to open fiber or interrupt service)
- Wavelength Range: 800 nm – 1700 nm
- Signal Types Detected: Continuous Wave (CW), live traffic, and modulated tones at 270 Hz, 1 kHz, and 2 kHz
- Signal Direction: Bi-directional traffic indication via LEDs (left/right arrows)
- Detector Sensitivity: Approx. −40 dBm to −50 dBm (varies by model)
- Insertion Loss: Typically <0.6 dB @ 1310 nm
Fiber Compatibility:- Fiber Types: Single-mode and multimode (most models support both)
- Adapter Heads (Interchangeable): 250 µm bare fiber, 900 µm coated fiber, 2.0 mm and 3.0 mm jacketed fiber, and ribbon fiber
Power & Physical:- Power: 9V alkaline battery (approx. 10,000 readings)
- Operating Temperature: −20°C to +50°C
- Dimensions/Weight: Approx. 190 × 32 × 25 mm / 213 g (varies by model)
Key Specs: Optical Fiber Identifier, Non-Destructive Macro-Bend Detection, 800–1700nm, Detects CW/Live Traffic + 270Hz/1kHz/2kHz Tones, Bi-Directional Traffic Indication, Interchangeable Adapters (250µm/900µm/2mm/3mm/Ribbon), 9V Battery, ±40dBm Sensitivity
Usage: Identifying Live Fibers Before Splicing or Cut-Over, Locating Specific Fibers in Bundles Without Service Interruption, Fiber Continuity Testing with Tone Generators, Maintenance & Rerouting in Telecom/Data Centers, Troubleshooting Mislabeled Fibers
