KSh 430(KSh 499 Incl VAT)
Device Type: Fixed Fiber Optic Attenuator (SC Simplex)
Attenuation Value: 10 dB
Connector Type: SC (Simplex Male-to-Female)
Polish Type: APC or UPC (Variant Dependent)
Fiber Mode: Singlemode
Operating Wavelength: 1260 – 1620 nm
Return Loss: ≥ 60 dB (APC) / ≥ 50 dB (UPC)
Attenuation Tolerance: ±10% (or ±0.5–0.7 dB depending on grade)
Max Optical Input Power: 200 – 250 mW
Ferrule Material: Zirconia Ceramic
Key Features: Precision Polished, Low PDL (≤0.2 dB), Dust Cap Included, Metal Shell, 500 Mating Cycles
Key Specs: 10dB SC Attenuator, Singlemode, APC/UPC, 1260-1620nm, Return Loss ≥60dB (APC), Zirconia Ferrule, Male-Female
Usage: FTTH/PON Power Balancing, CWDM/DWDM Systems, CATV, Optical Receiver Protection, Fiber Testing
Product Name: 10dB SC Singlemode Fiber Optic Attenuator
