Datasheet
Core Specifications
- Input Voltage: AC 100–240V worldwide compatibility (50/60Hz)
- Output Voltage: DC 12V (adjustable range typically 12V–13.8V on some models)
- Total Output Current: 5A maximum
- Total Output Power: 60W
- Number of Channels: 4 individual output ports for cameras
Output & Protection Features
- Individually Fused Outputs: Each channel has its own PTC resettable fuse (typically 1.1A–2A rating) to protect individual cameras
- Per-Channel Current Limit: Approximately 1.25A per port (some models up to 1.6A)
- LED Status Indicators: Per-channel LED lights show power/fuse status at a glance
- Multiple Protections: Includes short circuit, overload, overvoltage, overcurrent, and over-temperature protection with auto-recovery
- Auto-Reset Fuses: PTC fuses automatically reset after tripping, eliminating the need for replacement
Build & Installation
- Metal Enclosure: Durable, corrosion-resistant metal housing with a lockable design to prevent unauthorized access and insect/dust ingress
- Wall-Mountable: Compact design with mounting holes for easy wall installation
- On/Off Switch: Manual power control switch
- Efficiency: Typically 80–85% conversion efficiency
Physical Specifications
- Dimensions: Approximately 163 × 163 × 55 mm (varies by manufacturer)
- Weight: Approximately 800–830 g
- Operating Temperature: -10°C to +60°C
- Certifications: CE, FCC, RoHS (some models UL-listed)
