TPDIN-MONITOR-WEB2 A DIN-rail remote power monitor with web and SNMP
KSh 25,690(KSh 29,800 Incl VAT)
Comprehensive Remote Monitoring: Measures up to 4 DC voltages (1–80 VDC), 4 currents (I1/I2: 0.1–20A; I3: ±10A; I4: shunt input ±25mV), and 2 temperatures (T1 internal, T2 external sensor included; –40°C to +125°C) -2-4
Four On-Board Relays: 2 Normally Closed (CH1, CH2) and 2 Normally Open (CH3, CH4) relays for remote power control of connected equipment; rated 10A at 30VDC or 125–250VAC -1-4-17
Flexible Relay Automation: Relays can be controlled automatically based on Voltage, Current, Temperature, Ping Watchdog, Time, or Periodic schedules; supports compound control logic -2-4
Web & SNMP Access: Full remote management via any web browser or SNMP; includes a Tycon mobile app for iOS and Android for on-the-go access -4-8
On-Board Datalogger & Graphs: Stores up to 4,048 records with historical graphing capability for analyzing voltage, current, and temperature trends over time -2-12
Automatic Email Alerts: Sends up to 4 independent email alerts when programmed parameter limits are exceeded or on a periodic schedule -2-4
Dual Power Inputs: Powered via PoE (802.3af/at or Passive 24–48V) through RJ45 or 10–57VDC via wire terminal; the higher-voltage source takes priority automatically -1-4
One-Click Relay Cycle: Single-button relay cycling with programmable delay for rebooting connected equipment (e.g., power-cycling a PoE switch) -2-4
Bi-Directional Battery Monitoring: I3 port reads positive and negative current to determine whether a battery is charging or discharging -4-8
Field Calibration & Custom Labels: Each parameter supports programmable ± offsets for calibration (line loss compensation), and user-defined labels for easy identification -2-4
DIN Rail Mounting: Compact form factor (4.9 × 4 × 1.8 in) designed for control cabinets and power distribution panels in unattended sites -4-11
Wide Operating Temperature: Functions reliably from –40°C to +75°C for outdoor and industrial deployments -11-17
