KSh 791,410(KSh 918,036 Incl VAT)
Device Type: Online Double-Conversion Tower/Rack-Mountable UPS (Uninterruptible Power Supply)
Part Number/SKU: SURT10000XLI (also available as SURT10000RMXLI rackmount, 6U) — Note: This model was discontinued on Jan 31, 2026, with end-of-service Dec 31, 2025. Recommended replacement: SRT10KXLI
Brand: APC by Schneider Electric (Smart-UPS RT Series)
Capacity: 10000 VA / 8000 W (Power Factor 0.8)
Topology: Double-Conversion Online (True Online)
Input Voltage: 230 V AC, 1 Phase / 400 V AC, 3 Phase
Input Voltage Range: 160 – 280 V AC
Input Harmonic Distortion: < 7% at Full Load
Input Connection: Hard Wire 3-Wire (1P + N + E) or 5-Wire (3P + N + E)
Output Voltage: 230 V AC (Configurable 220 / 230 / 240 V)
Output Frequency: 50/60 Hz ± 3 Hz (User Adjustable ± 0.1 Hz Sync to Mains)
Output Waveform: Pure Sine Wave
Output Harmonic Distortion: < 3%
Crest Factor: 3:1
Outlets: 4 × IEC 60320 C13 + 6 × IEC Jumpers + 4 × IEC 60320 C19
Output Connection: Hard Wire 3-Wire (H N + E) for 1 Zone
Bypass: Internal Automatic & Manual Bypass
Battery Type: Maintenance-Free Sealed Lead-Acid (VRLA), Leakproof
Battery Configuration: 4 × Preinstalled Batteries
Battery Recharge Time: 2.2 Hours
Runtime (Full Load): ~4 Minutes at 8000 W
Runtime (Half Load): ~13.2 Minutes at 4000 W
Replacement Battery Cartridge: RBC44
Communication & Management: Preinstalled Network Management Card 2 with Environmental Monitoring; SmartSlot Available
Emergency Power Off (EPO): Yes
Efficiency: 92% at Full Load (Green Mode up to 98%)
Form Factor: Tower (Rack/Tower Convertible; 6U Rackmount via SURT10000RMXLI)
Dimensions (H×W×D): 432 × 263 × 736 mm
Weight: ~111 kg
Color: Black
Operating Temperature: 0°C to 40°C
Compliance: CE, EN/IEC 62040-1, EN/IEC 62040-2, RoHS, REACh
Warranty: 2 Years (Product)
Key Specs: APC SURT10000XLI, Smart-UPS RT 10kVA/8000W, 230V, Double-Conversion Online, Pure Sine Wave, 4× C13 + 6× IEC Jumpers + 4× C19 Outlets, Internal Bypass, VRLA Battery (RBC44), 4 Min Runtime at Full Load / 13.2 Min at Half Load, Network Management Card Included, EPO, Green Mode 98% Efficiency, Tower/Rackmount 6U, 111 kg
Usage: Small to Medium Data Centers, Enterprise Servers & Storage Arrays, Voice/Data Networks, Medical Laboratories, Light Industrial Applications, Mission-Critical Business Infrastructure
