Device Type: AC-to-DC CCTV Power Adapter (High-Capacity)
Brand/Model: Generic – 12V 5A Power Adapter (brand varies; e.g., Dahua DH-12V(5A), generic OEM)
Video Output: N/A
Data Ports: Output: DC Barrel Jack (typically 5.5mm × 2.1mm — verify on unit) or multi-way splitter cable; Input: AC plug (regional, e.g., UK 3-pin, EU 2-pin)
Power Specifications:- Input: 100–240V AC, 50/60Hz (universal)
- Output: 12V DC
- Rated Current: 5A (5000mA)
- Rated Power: 60W
- Efficiency: Level VI (typical for modern adapters)
Protection & Safety:- Overcurrent, Overvoltage, Short-Circuit Protection (standard on quality units; verify on your model)
- Surge/EMI shielding on metal-cased variants
Physical & Environmental:- Form Factor: Desktop power brick or metal-cased CCTV power box (varies by model)
- Output Cable Length: Typically 1.2m (verify)
- Operating Temperature: 0°C to +40°C (derating above +40°C)
- Certifications: CE, UL (varies by brand; Dahua model lists 1-year warranty )
Key Specs: 12V DC 5A (60W) CCTV Power Adapter, 100–240V AC Input, 5.5×2.1mm Barrel Jack or Splitter Cable (Verify), Level VI Efficiency, Sufficient for Multiple Low-Power Cameras (Up to 8 via Splitter) or One High-Power Device (PTZ/DVR/NVR) — Not Both Simultaneously
Usage: Powering Multiple Standard Analog/HDCVI/AHD/TVI Cameras via Splitter Cable (Up to 8 Low-Power Units), Powering a Single PTZ Camera, DVR, NVR, or Other 12V DC Device Requiring Up to 5A
