KSh 74,140(KSh 86,002 Incl VAT)
Device Type: 3kVA / 3000W True Online Double-Conversion Rack Mount UPS (Maxion Series)
Model / SKU: NPS-AC03R96IWB
Brand: Norden
Capacity: 3000 VA / 3000 W (Unity Power Factor, PF = 1.0)
Input: Phase: Single Phase with Ground; Normal Voltage: 208/220/230/240 VAC; Input Voltage Range: 110–300 VAC (176–264 VAC @ 100% Load; 276–300 VAC @ 50% Load); Frequency Range: 50/60 Hz Auto Sensing ±5 Hz; Input Power Factor: ≥0.99 @ Nominal Voltage (100% Load); Input Connection: IEC C19
Output: Output Voltage: 208/220/230/240 VAC (Selectable); Voltage Regulation: ±1%; Frequency (Battery Mode): 50/60 Hz ±0.1 Hz; Current Crest Ratio: 3:1; Harmonic Distortion (THDv): ≤2% (Linear Load) / ≤5% (Non-Linear Load); Transfer Time: AC to DC — Zero (0 ms); Inverter to Bypass — 4 ms; Waveform: Pure Sinewave; Output Connections: 8 × IEC C13
Efficiency: AC Mode: Up to 96%
Battery: Battery Type: 12V/9Ah VRLA (Valve Regulated Lead Acid); System Voltage: 96 VDC; Battery Configuration: 6 × 12V/9Ah (Internal) — Note: Some regional listings specify 8 × 12V/9Ah for the 3kVA rack model. The "WB" suffix typically denotes a "Without Battery" configuration — please confirm the exact battery inclusion with your supplier.; Typical Recharging Time: 4 hours to recover to 90% capacity; Charging Current (Max): 1A (Internal) / 1–12A (Settable); Charging Voltage: 108 VDC ±1%
Display & Alarms: LCD Indicators: Load Level, Battery Level, AC Mode, Battery Mode, Bypass Mode, and Fault Indicators; Audible Alarms: Battery Mode (Beep every 4 seconds), Battery Low (Beep every second), Overload (Beep twice every second), Fault (Continuous beeping)
Communication & Management: Communication: RS232 (Standard); USB, IoT Card, and SNMP Card (Optional); SNMP Support (as specified in product listing)
Protection: Overload, Short Circuit, Voltage Fluctuation; Built-in EMI Filter and Surge Protection; Emergency Power Off (EPO) Function; Cold Start Function
Physical: Form Factor: 2U Rack Mount (Rack/Tower Convertible); IP Rating: IP20
Environmental: Operating Temperature: 0°C to 40°C; Humidity: 0–95% RH @ 0–40°C (Non-Condensing); Noise Level: <50 dB @ 1 Meter
Key Specs: Norden NPS-AC03R96IWB Maxion Series 3kVA/3000W True Online Double-Conversion Rack Mount UPS, Unity Power Factor (1.0), Pure Sinewave Output, Zero Transfer Time (AC to DC), 8 × IEC C13 Outlets, IEC C19 Input, 96% Efficiency, Wide Input Range (110–300VAC), LCD Display, SNMP/USB/RS232/IoT Optional, EPO Function, 2U Rack Mount (Tower Convertible), 96V DC Battery System
Usage: Rack Servers, Network Cabinets, Telecommunication Equipment, Data Centers, Industrial Control Panels, Security & Surveillance Systems, and Mission-Critical IT Infrastructure
