Device Type: Three-Phase Online Double-Conversion Tower UPS (Uninterruptible Power Supply)
Part Number/SKU: E3SUPS10KHB (Base Model); E3SUPS10KHB1 (1 Battery String); E3SUPS10KHB2 (2 Battery Strings); E3SP10KHB2 (Easy UPS 3S Pro Variant)
Brand: APC by Schneider Electric (Easy UPS 3S Series)
Power Rating: 10 kVA / 10 kW (Unity Power Factor 1.0)
Topology: True Online Double-Conversion
Phase Configuration: 3:3 (3-Phase Input / 3-Phase Output)
Input:- Nominal Voltage: 400V AC 3-Phase (Configurable 380V / 415V)
- Input Voltage Range: 304–477 V AC
- Input Frequency Range: 45–65 Hz
- Maximum Input Current: 18 A per Phase
- Input Harmonic Distortion: <3% at Full Load
- Input Power Factor: 0.99
Output:- Nominal Voltage: 400V AC 3-Phase (Configurable 380V / 415V)
- Output Voltage Tolerance: ±1.5%
- Output Harmonic Distortion: <3% (Linear Load)
- Output Frequency: 50/60 Hz (Sync to Mains)
- Overload Capability: 130–150% for 1 Minute; 125–130% for 10 Minutes
Battery:- Battery Type: Valve-Regulated Lead-Acid (VRLA), Internal
- Battery Configuration: Modular 7Ah Strings; Expandable to 3 Strings
- Runtime (Full Load): Approx. 15 Minutes (1 String) / Approx. 40 Minutes (2 Strings)
Efficiency: High-Efficiency 3-Phase Design with ECO Mode
Display & Communication:- User Interface: Intuitive Graphical Display
- Network Management: Optional Network Management Card 3 (SNMP / Web Monitoring)
- USB Compatible: Yes
Physical & Environmental:- Form Factor: Free-Standing Tower
- Dimensions (W × D × H): 38 × 92.8 × 140 cm
- Weight: Approx. 112 kg (With Batteries)
- Colour: White (RAL 9003)
- Protection Rating: IP20
- Operating Temperature: 0°C to 40°C
Key Features:- Parallel Capable up to 4 UPSs for Capacity or Redundancy
- Internal Maintenance Bypass & EPO Switch
- Replaceable Dust Filters for Harsh Environments
- Conformal Coated Boards
- ECO Mode for High Efficiency
- Easy Loop Test for Pre-Deployment Verification
Key Specs: APC Easy UPS 3S E3SUPS10KHB, 10kVA/10kW Three-Phase Online Double-Conversion Tower UPS, 3:3 Phase, Unity PF, 400V AC (380/415V Configurable), 304–477V AC Wide Input Range, 45–65Hz, <3% Input/Output THD, Modular 7Ah Internal VRLA Battery Strings (Expandable to 3), Up to 40 Min Runtime with 2 Strings, Parallel Capable (Up to 4 Units), ECO Mode, Dust Filter, Conformal Coated Boards, Optional Network Management Card 3, White RAL 9003, 112kg
Usage: Small to Medium Data Centers, IT Rooms, Commercial Buildings, Enterprise Server Rooms, and Mission-Critical Applications Requiring High-Capacity Three-Phase Power Protection with Customizable Runtime
