DataseetDevice Type: Indoor Wi-Fi 6 Wireless Access Point
Brand/Model: Aruba Instant On AP22 (RW) – Part No. R4W02A
Video Output: N/A
Data Ports: 1× Gigabit Ethernet (10/100/1000BaseT) uplink port with PoE input; 1× 12V DC power interface; Bluetooth Low Energy (BLE) radio
Wireless Specifications:- Standard: Wi-Fi 6 (802.11ax), Wi-Fi CERTIFIED 6
- Radios: Dual-radio, simultaneous dual-band (2.4 GHz + 5 GHz)
- MIMO: 2×2 MU-MIMO (Multi-User MIMO) on both bands
- Max Data Rate: 5 GHz: 1.2 Gbps; 2.4 GHz: 574 Mbps; Aggregate: 1.7 Gbps
- Antennas: Integrated down-tilt omni-directional; Peak gain ~4.3 dBi (2.4 GHz) / ~5.6 dBi (5 GHz)
- Max Transmit Power: +21 dBm (5 GHz), limited by local regulations
- Wi-Fi 6 Features: OFDMA, Target Wake Time (TWT), BSS Coloring, 1024-QAM, MU-MIMO, Transmit Beamforming (TxBF), LDPC
- Client Capacity: Up to 75 associated clients per radio
Power & Environmental:- Power Input: PoE 802.3af (Class 3) OR 12V DC
- Max Power Consumption: 10.1W (PoE) / 8.8W (DC)
- Operating Temperature: 0°C to +40°C
- Operating Humidity: 5% to 93% (non-condensing)
Physical:- Form Factor: Wall or ceiling mountable (mounting clip included)
- Dimensions (W×D×H): 160 × 160 × 37 mm (approx.)
- Weight: Approx. 500 g
- MTBF: 91 years
Management & Security:- Management: Aruba Instant On mobile app or cloud web portal (no external controller required)
- Security: WPA2/WPA3, Enhanced Open (OWE), built-in firewall/gateway, Trusted Platform Module (TPM), 2FA for admin access
- Features: Smart Mesh, Guest Network (up to 8 SSIDs), Application Visibility & Control, PPPoE/Static IP, Bluetooth (BLE) for setup
- Included in Box: AP22 unit, Quick Start guide, ceiling/wall rail mount clip, Ethernet cable
Key Specs: Aruba Instant On AP22 (R4W02A), Wi-Fi 6 (802.11ax) Dual-Band AP, 2×2 MU-MIMO, 1.7 Gbps Aggregate (1.2G + 574M), 75 Clients/Radio, PoE 802.3af or 12V DC, WPA3, Smart Mesh, Instant On App/Cloud Management, Wall/Ceiling Mount
Usage: Small & Medium Business Wi-Fi, Retail & Hospitality Guest Networks, Home Offices, Warehouses & Manufacturing (Mesh Extension), High-Density Small Business Environments
