Device Type: Fiber Optic Cleaver (Handheld Precision Tool)
Brand/Model: Jilong KL-33F (One-Step Full-Metal Cleaver)
Video Output: N/A
Data Ports: N/A (manual mechanical tool; no electrical interfaces)
Performance & Cutting Specs:- Cleaving Angle: ≤ 0.5° (Typical)
- Blade Lifespan: 72,000 cleaves (replaceable blade)
- Cleaving Length: Single Fiber: 8–20 mm; Multi-Fiber: ~10 mm
- Fiber Compatibility: 125 µm cladding; 250 µm, 900 µm, 3.0 mm, and drop cable (Single-core); 2–12 core ribbon fiber
Physical & Build:- Material: All-metal CNC-machined body with rubber pressure pad
- Weight: ~253 g
- Dimensions: 80.34 × 95.54 × 50.57 mm
- Features: Tool-free blade position adjustment, automatic cleaver return system, anti-slip pressure mechanism
Key Specs: Jilong KL-33F Fiber Optic Cleaver, One-Step Full-Metal, Cleaving Angle ≤0.5°, Blade Life 72,000 Cleaves, Supports 250µm/900µm/3.0mm/Drop Cable & 2-12 Core Ribbon, Tool-Free Adjustment, ~253g
Usage: FTTH & Telecom Fiber Splicing, Fusion Splicing Preparation, Field Installation & Maintenance, Data Center Fiber Termination, Ribbon Fiber Processing
