KSh 2,860(KSh 3,318 Incl VAT)
Datasheet
Device Type: 1×16 PLC (Planar Lightwave Circuit) Fiber Optic Splitter Module
Brand/Model: Optace – 1:16, SC/UPC, ABS Box
Video Output: N/A (Passive optical component; no video interface)
Data Ports: 1× Input Port, 16× Output Ports; SC/UPC Connectors
Optical & Fiber Specifications:
Fiber Type: Single-mode G.657A1 or G.652D
Operating Wavelength: 1260 – 1650 nm
Insertion Loss: ≤ 10.6 dB (Note: generic 1×16 ABS modules are often rated ≤13.7 dB; the 10.6 dB figure is specific to the Optace listing)
Return Loss: ≥ 50 dB (SC/UPC)
Uniformity: ≤ 1.2 dB (typical for this class)
Polarization Dependent Loss (PDL): ≤ 0.3 dB
Directivity: ≥ 55 dB
Fiber Length: Typically 1 m or 1.5 m (varies by supplier)
Physical & Environmental:
Package Style: ABS Plastic Box (Module)
Dimensions (L × W × H): Approx. 120 × 80 × 18 mm
Operating Temperature: −40°C to +85°C
Storage Temperature: −40°C to +85°C
Key Specs: Optace 1×16 PLC Fiber Splitter, SC/UPC Connectors, ABS Box Module, 1260–1650 nm, Insertion Loss ≤10.6 dB, Return Loss ≥50 dB, Uniformity ≤1.2 dB, PDL ≤0.3 dB, Directivity ≥55 dB, 120×80×18 mm, −40 to +85°C
Usage: FTTx / FTTH Deployments (GPON/EPON/BPON), Passive Optical Networks (PON), CATV Systems, LAN/WAN & Metro Networks, Fiber Optic Test Equipment, Signal Distribution in Centralized or Distributed Splitting Architectures
