Device Type: Flush Mount Plate / Recessed Mounting Box for 8-Inch Face Recognition Outdoor Station
Model / SKU: DHI-VTM121 (Official Base Model: VTM121)
Brand: Dahua
Function: A purpose-built flush-mount adapter that allows compatible 8-inch face recognition outdoor door stations to be recessed neatly into a wall or surface, providing a clean, integrated finish for outdoor installations.
Compatible Door Stations: Dahua VTO Series – VTO6441F, VTO6421F, VTO7541G, VTO7521G, VTO6521F, VTO6541H, VTO6531H, VTO6521H, VTO6521H-D
Physical:- Product Dimensions (W×H×D): 373 mm × 143 mm × 67.5 mm (14.69" × 5.63" × 2.66")
- Packaging Dimensions: 413 mm × 182 mm × 104 mm (16.26" × 7.17" × 4.09")
- Gross Weight: 1.09 kg (2.40 lb)
- Casing Material: SPCC (Steel Plate Cold Rolled Commercial)
Environmental:- Operating Temperature: –30°C to +70°C (–20°F to +158°F)
- Operating Humidity: 10% RH – 90% RH
- Operating Altitude: 86 kPa – 106 kPa
- Operating Environment: Outdoor
Installation Method: Flush Mount (Recessed)
Key Specs: Dahua DHI-VTM121 Flush Mount Plate, for 8-Inch Face Recognition Outdoor Stations, Compatible with VTO6441F / VTO6421F / VTO7541G / VTO7521G / VTO6521F / VTO6541H / VTO6531H / VTO6521H / VTO6521H-D, SPCC Steel Construction, 373×143×67.5mm, 1.09kg Gross Weight, –30°C to +70°C Operating Temperature, 10%–90% RH Operating Humidity, Flush Mount, Outdoor Use
Usage: Professional Installation of Dahua 8-Inch Face Recognition Door Stations, Residential & Commercial Building Entrances, Apartment Complexes, Office Building Lobbies, Gated Communities, and Any Outdoor Entry Point Requiring a Clean, Recessed Mounting Finish for the Door Station
