Device Type: Springless Telescopic Straight Arm Barrier Gate (Smart Parking, Bidirectional)
Model / SKU: DHI-IPMECD-2062-L (official base model: IPMECD-2062; the -L suffix denotes left-side configuration)
Brand: Dahua
Arm Type: Telescopic Straight Arm (Springless Design)
Arm Length: Adjustable 2.7 m – 6 m (8.86 ft – 19.69 ft)
Compatible Arm Models: IPMECD-0262-M30-LED, IPMECD-0262-M40-LED, IPMECD-0262-M50-LED, IPMECD-0262-M60-LED, IPMECD-0262-M2745 (2.7–4.5 m adjustable), IPMECD-0262-M4560 (4.5–6 m adjustable)
Opening/Closing Time: 1.4 – 6 seconds (speed depends on arm length and weight)
Motor: 24 VDC Brushless DC Motor (Quiet, Low Power Consumption, Stable, and Efficient)
Rotational Speed: 1,500 RPM
Transmission Ratio: 88:1
Motor Lifespan: 6 Million Operations
Directional Configuration: Left/Right Interchangeable (Right by Default); Supports Quick Switching Between Directions
Anti-Smashing & Safety Functions:- Supports External Radar, Loop (Inductive Coil), and IR Anti-Smashing Functions
- Auto-Lifting Against Obstruction: Barrier Arm Automatically Rises When It Makes Contact with an Object
- Auto-Opening in Power Failure: Yes
- Manual Hand Crank Control in Power Failure: Yes
- Anti-Drop Function: Yes
- Built-in 12 VDC Output: For Powering External Radar (12 V ± 5%, Max 1 A)
Remote Control:- Supports Remote Control at a Maximum Distance of 50 m (164 ft) in Open Space
- Included: 2 Remote Controls; Supports Up to 40 Pairable Remote Controllers
Communication & Monitoring:- RS-485 Port: 1 Channel — Allows Connection to a Camera; Barrier Status (Operation Count, Operating Status, Operation Log) Can Be Read on the Camera's Web Interface
- I/O: 1 Channel
- Status Output: 2 Channels (One Fully Open, One Fully Closed)
- Bluetooth: GFSK, π/4-DQPSK; Frequency Range 2.402 GHz – 2.480 GHz ISM Band
- Sub-1G Wireless: ASK Modulation; Frequency Range 433.82 MHz – 434.02 MHz
Count Mode: Yes — Supports Operation Counting
Power Supply: 100–264 VAC (Full-Voltage)
Power Consumption: < 432 W
Protection: IP54 (Dust and Water Splash Resistant)
Anti-Corrosion Level: Basic Protection
Environmental:- Operating Temperature: –40 °C to +70 °C (–40 °F to +158 °F)
- Storage Temperature: –40 °C to +70 °C (–40 °F to +158 °F)
- Operating Humidity: 10%–90% RH (Non-Condensing)
- Storage Humidity: 10%–90% RH (Non-Condensing)
Physical:- Product Dimensions (L × W × H): 340.0 mm × 260.0 mm × 978.0 mm (13.39" × 10.24" × 38.50")
- Packaging Dimensions: 1,058.0 mm × 375.0 mm × 425.0 mm (41.77" × 14.76" × 16.73")
- Net Weight: 37.6 kg (82.89 lb) — Without Barrier Arm
- Gross Weight: 43.2 kg (95.24 lb)
- Housing Material: Corrosion-Resistant Cold-Rolled Sheet Metal (Metal Stamping Process)
- Installation: Bottom-Mounted with Expansion Bolts
Key Specs: Dahua DHI-IPMECD-2062-L Springless Telescopic Straight Arm Barrier, 2.7–6m Adjustable Arm, 24VDC Brushless Motor (1500 RPM), 1.4–6 Second Opening/Closing, 6 Million Operations Lifespan, Springless Design, Left/Right Interchangeable, Auto-Lifting Against Obstruction, Auto-Opening in Power Failure, Manual Hand Crank in Power Failure, 50m Remote Control Range (2 Remotes Included), RS-485 & Bluetooth Communication, IP54 Protection, 100–264 VAC, <432W Power Consumption, –40°C to +70°C Operating Temperature, 340×260×978mm, 37.6kg (Without Arm), Cold-Rolled Sheet Metal Housing
Usage: Vehicle Access Control, Parking Facilities, Toll Gates, Residential & Commercial Entrances, Industrial Sites, High-Flow Traffic Zones, and Any Installation Requiring a Reliable, High-Speed Telescopic Barrier Arm with Safety Protection and Remote Monitoring Capabilities
