KSh 51,730(KSh 60,007 Incl VAT)
Device Type: 32-Channel 1U 16PoE 2HDD WizSense Network Video Recorder
Model / Part Number: Dahua DHI-NVR5232-16P-EI
IP Camera Input: 32 Channels
Network Bandwidth: AI Disabled: 384 Mbps In / 384 Mbps Record / 384 Mbps Out; AI Enabled: 200 Mbps In / 200 Mbps Record / 200 Mbps Out -1-9
Recording Resolution: 32MP / 24MP / 16MP / 12MP / 8MP / 6MP / 5MP / 4MP / 3MP / 1080p / 960p / 720p / D1 / CIF / QCIF -1-9
Video Compression: Smart H.265+ / H.265 / Smart H.264+ / H.264 / MJPEG -1
Decoding Capability: 32 × 1080p@30 fps; 16 × 4MP@30 fps; 8 × 8MP@30 fps; 2 × 32MP@25 fps -1-9
Video Output: 1 × HDMI (up to 4K), 1 × VGA (heterogeneous output) -9
HDD Interface: 2 × SATA III, up to 10TB per HDD; supports iSCSI -2-11
PoE Ports: 16 × RJ-45 (10/100 Mbps, IEEE802.3af/at), Ports 1-8 support ePoE & EoC, Total 130W budget, Max 25.5W per port -13
AI by Recorder: 2-ch Face Detection & Recognition, 4-ch Perimeter Protection, 8-ch SMD Plus -1-9
AI by Camera: Face Detection & Recognition, Perimeter Protection, SMD Plus, Metadata, ANPR, People Counting, Stereo Analysis, Crowd Distribution, Heat Map, PPE Detection -1-2
Face Database: Up to 20 databases, 20,000 face images, 2.5GB total capacity -1-9
AcuPick: Max. 16-channel (AI by Recorder) -1
Alarm I/O: 4 Input, 2 Output -9-13
Network Port: 1 × RJ-45 10/100/1000 Mbps -11
USB Ports: 1 × USB 3.0 (Rear), 1 × USB 2.0 (Front) -11
Power Supply: AC 100–240V, 50/60 Hz -4-7
Power Consumption: ≤ 10W (without HDD) -4-13
Operating Temperature: –10°C to +55°C -4-7
Dimensions: 375 mm × 329.3 mm × 53 mm -7-13
Weight: 2.66 kg (Net) -4-7
Key Specs: Dahua DHI-NVR5232-16P-EI, 32-Channel PoE NVR, WizSense Series, 16 PoE Ports (130W, ePoE 1-8), 4K HDMI Output, Smart H.265+, 32MP Recording, 2 HDD Bays (20TB), AI by Recorder (Face Recognition, Perimeter Protection, SMD Plus), AcuPick 16-Channel
Usage: Medium to Large Business Surveillance, Retail Shops, Offices, Warehouses, Campus Security, and Commercial Security Systems
