KSh 1,150(KSh 1,334 Incl VAT)
Device Type: Conventional Heat Detector
Model / Part Number: Dahua DHI-HY-C132
Working Voltage: DC 16V–28V -2-5
Rated Power: 3.408mW -2-5
Standby Current: ≤ 120μA -2-5
Alarm Current: ≤ 170μA -2-5
Sensor Type: A2R (Rate of Rise + Fixed Temperature) -1-14
Fixed Alarm Threshold: 62°C ± 3°C -14
Alarm Mode: Visual Alarm -2-5
Coverage Area: H ≤ 4m: 50 m²; 4m ≤ H ≤ 12m: 30 m² -2-5
Operating Temperature: –10°C to +50°C -2-5
Operating Humidity: ≤ 95% RH (No Condensation) -2-5
Dimensions (with base): Φ100 mm × 50 mm -2-5
Weight (with base): 81 g -2-5
Installation: Ceiling Mount -2-5
Compliance Standard: EN 54-5: 2017/A1:2018 -2-5
Key Specs: Dahua DHI-HY-C132, Conventional Heat Detector, Two-Wire Polar-Free, DC 16-28V, Rate-of-Rise + Fixed Temperature, 62°C Alarm Threshold, EN54-5 Certified
Usage: Kitchens, Boiler Rooms, Generator Rooms, Parking Garages, Workshops, Industrial Facilities
