Device Type: 16-Channel Penta-brid WizSense Digital Video Recorder (XVR)
Brand/Model: Dahua DH-XVR1B16-I/T
Video Output: 1x HDMI (up to 1920×1080), 1x VGA (up to 1920×1080)
Data Ports: 16x BNC (HDCVI/AHD/TVI/CVBS auto-detect); 1x RJ-45 10/100 Mbps Ethernet; 2x USB 2.0; 1x SATA (HDD up to 16TB for newer variants)
IP Camera Support: Up to 18 channels (2 IP by default + 16 analog convertible); up to 6MP per channel; 64 Mbps incoming bandwidth
Two-Way Talk: 16-channel two-way talk over coaxial cable (the "/T" model feature)
AI Features: 16-channel SMD Plus (human/vehicle filtering) for analog channels or 18-channel SMD by camera; AI Coding
Compression: Smart H.265+, H.265, Smart H.264+, H.264
Recording Resolution: 1080N/720P (Main stream: 1st channel up to 25/30fps; others up to 15fps)
HDD Support: 1x SATA port (up to 16TB per newer listings; older variants 6TB)
Key Specs: Dahua XVR1B16-I/T, 16CH Penta-brid XVR, 1080N/720P, WizSense, 16-Ch Coaxial Two-Way Talk, 16-Ch SMD Plus, AI Coding, Smart H.265+, Up to 18 IP Channels (6MP), 1x HDD, HDMI/VGA
Usage: Small to Medium CCTV Systems, Hybrid Analog/IP Upgrades, Retail/Office/Home Surveillance, Two-Way Audio Communication
