Ports & Interface
- 1× RJ45: 10/100 Mbps Ethernet port for connecting to the network or NVR.
- 1× BNC: Coaxial interface for connecting to the coaxial cable.
- MDI/MDIX: Supports self-adaptation for automatic cable type detection.
Transmission Performance
The extender supports long-range power supply transmission over coaxial cable, with performance depending on the speed and cable type:
- RG59 Cable: Up to 400 meters at 100 Mbps, or up to 1000 meters at 10 Mbps.
- PoE Support: Compatible with IEEE 802.3af/at PoE standards and Dahua's ePoE technology, enabling both data and power to be transmitted over a single coaxial cable.
Protection & Reliability
- Lightning Protection: Up to 4KV in common mode and 2KV in differential mode.
- Operating Temperature: -30°C to +65°C, suitable for various outdoor and industrial environments.
- Power Consumption: Approximately 2W.
- Dimensions & Weight: Compact form factor of 79 × 52 × 23 mm and 61 grams.
