Dahua CS4006-4ET2GT-36, 6-Port Cloud Managed Switch, 4× PoE (36W Budget) + 2× Gigabit Uplink, DoLynk Cloud, 250m Extend Mode

Device Type: 6-Port Cloud Managed Desktop Switch with 4-Port PoE
Brand/Model: Dahua CS4006-4ET2GT-36
Video Output: N/A
Data Ports: 4× RJ-45 10/100 Mbps PoE (Ports 1–4); 2× RJ-45 10/100/1000 Mbps Gigabit Uplink (Ports 5–6)
Switching & Performance:
Switching Capacity: 4.8 Gbps
Packet Forwarding Rate: 3.57 Mpps
MAC Address Table: 2K entries
Packet Buffer: 4 Mbit
Jumbo Frame: 9,216 bytes
MTBF: 232.62 years
PoE Specifications:
PoE Standard: IEEE 802.3af / 802.3at
PoE Power per Port: ≤ 30 W (Ports 1–4)
Total PoE Budget: 36 W
PoE Pin Assignment: 1, 2, 4, 5 (V+) / 3, 6, 7, 8 (V−)
PoE Watchdog: Auto-restarts PoE port when no traffic for 2 minutes (unmanaged mode)
Management & Networking:
Management: Web-managed (local) + Cloud-managed via DoLynk App (real-time monitoring, fault alarms, topology visualization via LLDP)
VLAN: 32 VLANs (IEEE 802.1Q)
Loop Protection: Alarm + kill mechanism to prevent broadcast storms
Other Features: Port isolation, N:1 mirroring, local port mirroring, DHCP client, storm control (broadcast/multicast/unknown unicast)
Hardware & DIP Switch:
DIP Switch Modes: Managed Mode (default on), PoE Watchdog, Extend Mode (Ports 1–4 up to 250 m at 10 Mbps)
Reset Button: 1×
Power & Environment:
Power Supply: External 53 VDC, 0.8 A
Power Consumption: Idle ≤3 W / Full Load 42.4 W
Operating Temperature: −10°C to +55°C
Storage Temperature: −40°C to +70°C
Protection: Lightning (common mode 6 kV), ESD (air 8 kV / contact 6 kV)
Physical:
Dimensions (L×W×H): 115 × 84 × 27 mm
Net Weight: 0.2 kg
Casing: Sheet Metal
Installation: Desktop or Wall-Mount
Key Specs: Dahua CS4006-4ET2GT-36, 6-Port Cloud Managed Desktop Switch, 4× 10/100 Mbps PoE + 2× Gigabit Uplink, 36W PoE Budget (802.3af/at, ≤30W/port), 4.8Gbps Switching Capacity, L2 Managed, DoLynk Cloud App, PoE Watchdog, 250m Long-Distance PoE, VLAN 32, Loop Protection, 53VDC External PSU
