KSh 11,500(KSh 13,340 Incl VAT)
Device Type: Standalone Access Controller & Reader (Fingerprint, Card, Password)
Model / SKU: Dahua DHI-ASI1212M-P (ASI1212M-P)
Verification Methods: Fingerprint, IC Card (Mifare 13.56 MHz), Password, Remote
User Capacity: 10,000 Users / 10,000 Cards / 10,000 Passwords / 3,000 Fingerprints
Record Capacity: 100,000 Records
Fingerprint Sensor: Capacitive, 1:N Mode; Comparison Time ~1.5s, Recognition Time ~0.5s
Card Reading Distance: 0–30 mm
Communication: TCP/IP, RS-485, Wiegand (26/34/66 bit), OSDP
Power Supply: Standard PoE or 12V DC, 1.5A; Max Consumption ≤18W
Protection Rating: IP65 (Weatherproof) & IK08 (Vandal-Resistant)
Casing Material: Zinc Alloy Front Panel + Plastic Back
Keypad: Mechanical Keypad with Backlight
Alarm I/O: 2 Alarm Inputs, 1 Alarm Output (also used for Doorbell)
Dimensions: 169 mm × 57.5 mm × 33.3 mm
Operating Temperature: -30°C to +60°C
Key Features: Anti-passback, Tamper Alarm, Duress Alarm, Door Sensor Timeout, Intrusion Alarm, Illegal Card Threshold, Web Configuration, Supports SmartPSS Lite / DSS PRO / DMSS
Key Specs: Dahua DHI-ASI1212M-P Standalone Access Controller, Fingerprint + Mifare Card + Password, 10,000 Users / 3,000 Fingerprints / 100,000 Records, TCP/IP & PoE, Wiegand/RS-485/OSDP, IP65 & IK08 Rated, Zinc Alloy Front, Mechanical Backlit Keypad, Anti-Passback & Tamper Alarm
Usage: Secure access control for single doors in offices, residential buildings, and commercial facilities; suitable for indoor and outdoor installation (IP65) where multiple authentication methods (fingerprint, card, PIN) and network-based management are required.
