Device Type: SFP/SFP+ Optical Transceiver Module (Single-Mode)
Brand/Model: Cisco (Common models: GLC-LH-SMD, SFP-10G-LR-S)
Video Output: N/A
Data Ports: 1× Duplex LC/PC Connector (Single-Mode Fiber)
Performance & Fiber Specs (By Speed):- 1G (1000BASE-LX/LH): Data rate 1.25 Gbps; Wavelength 1310 nm; Max reach up to 10 km over G.652 Single-Mode Fiber (SMF).
- 10G (10GBASE-LR): Data rate 10 Gbps; Wavelength 1310 nm; Max reach up to 10 km over OS1/OS2 SMF.
Environmental & Compliance:- Temperature Range: Standard Commercial (COM) is 0 to 70°C; Industrial (IND) variants are available for -40 to 85°C environments.
- Digital Diagnostics: Supports DOM (Digital Optical Monitoring) for real-time power/temperature tracking (standard on "D" suffix models like GLC-LH-SMD).
- Compliance: MSA compliant, hot-swappable, RoHS compliant.
Key Specs: Cisco Single-Mode SFP/SFP+, 1G or 10G Options, 1310nm Wavelength, 10km Reach, Duplex LC, DOM Support (Model Dependent), Commercial or Industrial Temp
Usage: Campus Backbones, Data Center Interconnects, Enterprise Switch/Router Uplinks, Long-Distance LAN/WAN Links
