KSh 33,340(KSh 38,674 Incl VAT)
Device Type: Line-Interactive Tower UPS (Standby Topology with AVR)
Part Number/SKU: BX2200MI-MS
Brand: APC (by Schneider Electric)
Output Power Capacity: 1200 Watts / 2200 VA
Topology: Line-Interactive with Automatic Voltage Regulation (AVR)
Nominal Input Voltage: 230V AC, Single Phase
Input Voltage Range: 140 – 300V AC
Input Frequency: 50/60 Hz ± 5 Hz (Auto-Sensing)
Nominal Output Voltage: 230V AC
Output Frequency: 50/60 Hz ± 1 Hz (Sync to Mains)
Output Waveform (On Battery): Stepped Approximation to Sine Wave
Outlets: 4× Universal Sockets (Battery Backup + Surge Protection)
Transfer Time: 6 ms Typical / 10 ms Maximum
Battery Type: Lead-Acid, Sealed Maintenance-Free (Internal)
Battery Voltage: 24V
Battery Volt-Amp-Hour Capacity: 190 VAh (Idle) / 216 VAh (Card Reader)
Typical Recharge Time: 8 Hours
Battery Life: 3 – 5 Years
Runtime (Full Load): ~1 Minute at 1200W
Runtime (Half Load): ~8.5 Minutes at 600W
Surge Energy Rating: 273 Joules
Dataline Protection: None (Not Specified)
Communication Port: USB Compatible (Auto-Shutdown Software Support)
Display: LED Status Indicators (On Line / On Battery)
Special Features: Cold-Start Capability, Automatic Self-Test, Surge Suppression, Compact Tower Design
Dimensions (H×W×D): 19.0 × 14.0 × 39.0 cm
Weight: 12.3 kg
Operating Temperature: 0°C to 40°C
Humidity: 0–95% Non-Condensing
Protection Rating: IP20
Acoustic Level: 40 dBA
Compliance: CE, EN/IEC 62040-1, EN/IEC 62040-2, RoHS
Warranty: 2 Years (Product)
Key Specs: APC BX2200MI-MS, Back-UPS 2200VA/1200W, 230V, Line-Interactive with AVR, 4× Universal Sockets, Stepped Sine Wave Output, 6ms Transfer Time, 273 Joules Surge Protection, USB Connectivity, Lead-Acid Battery, 8-Hour Recharge, Tower Form Factor, 12.3kg
Usage: Home Office Workstations, Desktop Computers, Gaming PCs, Small Business Equipment, Networking Devices, CCTV Systems, Point-of-Sale Terminals, Modems/Routers, Protection Against Power Outages, Voltage Fluctuations & Surges
