Wall-mount network data cabinet, 9U 600×600 mm, compact 19-inch rack enclosure designed for small-to-medium IT, telecom, and CCTV installations.

Device Type: 9U Wall-Mount Rack Cabinet (19-inch)
Cabinet Dimensions (W × D × H): 600 × 600 × ~492–519 mm (height varies by manufacturer; common values are 492 mm, 500 mm, 502 mm, 505 mm, and 519 mm)
Rack Capacity: 9U internal space
Equipment Width: 19-inch standard (482.6 mm modular spacing)
Load Capacity: 27 – 120 kg static load (varies significantly by manufacturer; 40 kg and 60 kg are the most common ratings, with some models rated at 27 kg, 70 kg, or 120 kg)
Protection Rating: IP20 (standard indoor); some models available in IP54 or IP55 for outdoor/harsher environments
Impact Resistance: IK08 on some models (5 joules mechanical impact)
Material: Cold-rolled steel (SPCC), powder-coated finish; common thickness 1.0–1.5 mm
Front Door: Lockable, tempered glass (4–5 mm) or perforated steel, depending on model; some doors are reversible
Side Panels: Removable, lockable (key lock); some models require opening the front door first for access
Cable Entry: Pre-cut entries at top, bottom, and rear (varies by model)
Ventilation: Passive perforations; provision for optional fan mounting in the roof/top panel
Usable Installation Depth: Approx. 529.5 mm (common for Lanberg models)
Included Accessories: Rack rails, M6 cage nuts, mounting screws, keys, earthing cable (varies by model)
Key Specs: 9U 19-inch Wall-Mount Cabinet, 600 × 600 mm Footprint, 27–120 kg Load Capacity (Commonly 40–60 kg), IP20 (IP54/IP55 Available), Cold-Rolled Steel (SPCC), Lockable Tempered Glass/Perforated Door, Removable Lockable Side Panels, Top/Bottom/Rear Cable Entry, Optional Fan Mounting, ~529.5 mm Usable Depth
Usage: Network Closets & Small Server Rooms, CCTV & IP Surveillance Equipment Housing, Alarm/Access Control Low-Voltage Systems, Telecom & IT Cabling, Home & Office Rack Installations
