Device Type: 4-Channel Penta-brid 5MP Compact 1U 1HDD WizSense Digital Video Recorder (XVR)
Video Output: 1× HDMI (up to 4K/3840×2160), 1× VGA (up to 1080p)
Data Ports: 1× RJ-45 10/100 Mbps Ethernet, 1× RS-485, 2× USB 2.0 (1 front, 1 rear)
Analog Input: 4× BNC (HDCVI/AHD/TVI/CVBS auto-detect)
IP Input: Up to 6 channels (2 IP by default + 4 analog convertible); max 6MP per channel; 32 Mbps incoming bandwidth
HDD Support: 1× SATA port, up to 16TB (HDD not included)
AI Features: 4-channel SMD Plus (human/vehicle filtering), 4-channel Perimeter Protection (Tripwire/Intrusion), 1-channel Face Recognition (10,000 images), 1-channel QuickPick 2.0, 4-channel AI Coding
Audio: 1× RCA Audio In, 1× RCA Audio Out, 4-channel BNC Coaxial Audio; Two-way Talk (shared with channel 1)
Compression: Smart H.265+ / H.265 / Smart H.264+ / H.264
Power: 12V DC, 1.5A; Consumption <5W (without HDD)
Physical: 260.0 × 237.8 × 47.6 mm; 0.84 kg (net)
Key Specs: Dahua DH-XVR5104HS-5M-I3, 4CH Penta-brid 5MP XVR, 4× BNC + 6 IP Channels (6MP), 1× HDD up to 16TB, 32 Mbps Bandwidth, 4-Ch SMD Plus, 4-Ch Perimeter Protection, 1-Ch Face Recognition, QuickPick 2.0, H.265+, HDMI/VGA, RS-485
Usage: Small CCTV Systems, Hybrid Analog/IP Upgrades, Retail/Office/Home Surveillance, AI-Assisted Human/Vehicle Detection and Face Recognition
