Device Type: Intelligent Hybrid Inverter/Charger (Off-Grid / Solar-Ready)
Part Number/SKU: SHADENTERPRISES_NSMaxPro2000
Brand: NS (Max Pro Series)
Power Rating: 2000 VA / 1800 W Continuous
Topology: Hybrid Off-Grid Inverter with Built-in MPPT Solar Charge Controller
Output Waveform: Imported Simulated Sine Wave
Inverter Output:- Continuous Power: 1800 W
- Nominal Output Voltage: 220 / 230 / 240 V AC
- Output Frequency: 50 / 60 Hz (Auto-Detecting)
Solar Charging (Built-in MPPT):- MPPT Charge Controller: Built-in 55 A
- Max Solar Input Power: 1650 W
- Solar Panel Support: Up to 4 × 410 W Panels
- MPPT Technology: Yes
Battery System:- Nominal Battery Voltage: 24 V DC
- Battery Configuration: 2 × 12 V Batteries in Series
- Charging Algorithm: Intelligent 3-Stage Charger Control for fast, safe, and efficient charging
AC Charging (Grid/Generator):- Wide Input Voltage Range: 170–280 V AC
- Automatic Line-to-Battery Switchover: Yes
Protection Features:- Full Protection Suite (Overload, Short-Circuit, Over-Temperature, Deep-Discharge, and Overcharge Protection)
Display & Interface:- Display: LCD Panel (Real-Time System Status) and/or LED Indicators
Physical & Environmental:- Design: Compact Size, Low Noise Operation
- Load Capacity: Capable of running up to 50 LED bulbs and 12 fans (depending on power consumption)
Key Specs: NS Max Pro 2000, 2000VA/1800W Intelligent Hybrid Inverter/Charger, Built-in 55A MPPT Solar Charge Controller, Simulated Sine Wave Output, 24VDC Battery System, 3-Stage Intelligent Charging, Automatic Line-to-Battery Switchover, 170–280VAC Input Range, LCD Display, Supports up to 1650W Solar Input, Compact & Low Noise
Usage: Home & Small Business Backup Power, Off-Grid Solar Systems, Areas with Unstable Electricity Supply, Running Everyday Household Appliances (LED Bulbs, Fans, Televisions, Computers, Routers), Reducing Electricity Costs, and Improving Energy Independence.
