Ultra-Rugged Durability
The DS3678 is engineered to survive drops, tumbles, and harsh conditions that would destroy standard scanners
.
- Sealing: It has an IP67 rating, meaning it is dust-tight, spray-proof, and waterproof. It can even be submerged in water .
- Drop & Tumble: It is built to withstand 8 ft (2.4 m) drops to concrete and 5,000 tumbles, ensuring it keeps working after rough handling .
- Temperature Range: It operates reliably in extreme conditions, with an operating range of -20°C to +50°C (-4°F to 122°F), making it suitable for freezer environments .
🔍 High-Performance Scanning
The advanced 2D imager captures virtually any barcode, in any condition, with lightning speed
.
- Barcode Types: It reads all standard 1D, 2D, and Digimarc barcodes, including damaged, dirty, poorly printed, or screen-displayed codes .
- Models & Range:
- DS3678-SR (Standard Range): Captures barcodes from near contact up to 5 ft (1.5 m) away .
- DS3678-ER (Extended Range): Reads barcodes from 0.076 m up to 21.3 m, ideal for high warehouse shelves .
- DS3678-DP (Direct Part Marking): Specialized with advanced illumination to read DPM codes (dot peen, laser etch, chemical etch) on shiny, curved, or low-contrast surfaces .
Cordless & Connectivity
- Wireless: Uses Bluetooth 4.0 Low Energy for fast, energy-efficient communication with a range of up to 100 m (328 ft) .
- Wi-Fi Friendly Mode: This feature prevents interference with your existing Wi-Fi network, ensuring stable connectivity .
- USB Kit: The kit typically includes the scanner, a rugged cradle, a shielded USB cable, and a power supply. The cradle provides a sealed charging and communication base .
- Battery & Management
- Battery Life: Powered by a 3100 mAh Lithium-Ion battery, it delivers up to 100,000 reads per charge, lasting through long shifts .
- Remote Management: Free tools like 123Scan and Scanner Management Service (SMS) allow you to remotely configure scanners, update firmware, and monitor battery statistics .
