The
UniFi Switch Enterprise XG 24 (Gen1) – USW-EnterpriseXG-24 is a high-performance, fully managed Layer 3 switch designed for enterprise environments requiring robust connectivity and advanced networking features. It offers a combination of 24 multi-gigabit 10G RJ45 ports and 2 high-speed 25G SFP28 fiber ports, making it ideal for supporting high-density access points, servers, and other network devices. The switch is managed via the UniFi Network Controller, providing centralized management and monitoring capabilities.
🔧 Hardware Specifications
- Ports:
- 24 × 10G RJ45 ports (auto-sensing 1G/2.5G/5G/10G)
- 2 × 25G SFP28 fiber ports
- Switching Capacity: 580 Gbps
- Total Non-Blocking Throughput: 290 Gbps
- Forwarding Rate: 431.52 Mpps
- MAC Address Table Size: 32,000 entries
- Layer 3 Features:
- DHCP Server (Local Networks)
- DHCP Relay
- Inter-VLAN Routing (Local Networks)
- Static Routing (Local Networks)
- Layer 2 Features:
- LACP Port Aggregation
- STP & RSTP
- QoS (DSCP)
- Pro AV Profiles (Play, Dante, Q-SYS, NDI, SDVoE, Shure, AES67, Crestron)
- Advanced IGMP Configuration (Querier, Fast Leave, Router Port)
- IGMP Snooping
- 802.1X Control
- MAC-Based ACLs & Device Isolation
- DHCP Snooping & Guarding
- Egress Rate Limit
- Flow Control
- Storm Control
- Multicast & Broadcast Rate Limiting
- MAC Address Blocking
- IP-Based ACLs & Network Isolation
- MAC-Based Port Restriction
- Port Isolation
- Port Mirroring
- Jumbo Frames
- LLDP-MED
- Voice VLAN
- Loop Protection
- Power Supply:
- Internal AC/DC, 100W
- Supports UniFi SmartPower Redundant Power System (USP-RPS) for backup power
- Power Consumption:
- Maximum (excluding PoE output): 100W
- Power Input:
- Universal AC input: 100–240V AC, 50/60 Hz
- USP-RPS DC input: 11.5V DC, 8.7A
- Physical Dimensions:
- 442 x 44 x 285 mm (17.4 x 1.7 x 11.2")
- Weight: 4.5 kg (9.9 lb) without mounting brackets
- Enclosure Material: SGCC steel
- Mounting: Rack mount (1U)
- Display: 1.3" color touchscreen for system and connection insights
- Operating Temperature: -5 to 40° C (23 to 104° F)
- Operating Humidity: 10 to 95% noncondensing
- Certifications: CE, FCC, IC
- ESD/EMP Protection:
- Air: ±16kV
- Contact: ±12kV
The
UniFi Switch Enterprise XG 24 (Gen1) is ideal for enterprise environments that require a high-performance, multi-gigabit switch with advanced Layer 2 and Layer 3 features, robust connectivity options, and seamless integration into the UniFi ecosystem. Its combination of 10G RJ45 ports and 25G SFP28 uplinks ensures flexibility and scalability for growing network demands.
