UBIQUITI NanoStation M5 150 Mbit/s White (PoE) (NSM5)

Datasheet
Antenna & Performance

• Integrated Dual-Polarity Antenna: Features a panel antenna with a gain of 14.6–16.1 dBi and dual-linear polarization for robust MIMO performance .
• Long Range & Throughput: Capable of high-speed links over 15 km+ with a throughput of 150+ Mbps, making it ideal for WISP deployments or connecting remote buildings .
• airMAX TDMA Technology: Unlike standard Wi-Fi, its proprietary Time Division Multiple Access protocol eliminates hidden node collisions, maximizing airtime efficiency and reducing latency for a stable, scalable network .

Power & Connectivity

• Passive PoE: Powered via a 24V, 0.5A PoE adapter (included). It supports an input voltage range of 22–27V DC and consumes a maximum of 8W .
• Dual Ethernet Ports: Includes two 10/100 Mbps RJ45 ports. The secondary port features software-enabled PoE passthrough, allowing you to power an external device like a security camera directly from the NanoStation, simplifying IP video integration .

Hardware & Durability

• Weatherproof Design: Housed in an outdoor UV-stabilized polycarbonate enclosure, it operates reliably in harsh conditions with a temperature range of -30 to 75°C .
• Compact & Lightweight: Measures 294 x 31 x 80 mm and weighs only 400 g, making it easy to mount on poles or towers without heavy structural support .
• Pole Mounting: Comes with a pole-mount kit included for straightforward installation .

Management & Features

• Versatile Modes: Supports AP, Client, and WDS modes with intelligent QoS that prioritizes voice and video traffic for seamless streaming .
• Powerful Software: Managed by Ubiquiti's AirOS, which provides advanced features like signal strength monitoring via on-board LEDs and remote hardware reset capability .
• Certifications: Compliant with FCC, IC, CE, and RoHS standards, and is NDAA compliant .
