Centralized Management Scale
The controllers vary by capacity, letting you choose based on network size.
- OC200/OC220 (Small to Medium): Manage up to 100 Omada Access Points, 10 Gateways, and 20 Switches. They also support up to 2 DeltaStream GPON OLTs .
- OC300 (Medium to Large): Scales up to 500 Access Points, 100 Switches, and 100 Gateways .
- OC400 (Large Enterprise): Designed for up to 1,000 Access Points, 200 Switches, and 100 Gateways .
Hybrid Cloud & Local Access
Enjoy the best of both worlds: on-premises management for maximum security and stability, plus free cloud access to monitor and configure your network remotely via the Omada App or Web UI, with no license fees .
Hardware & Deployment
- Flexible Power: The OC200 and OC220 can be powered via 802.3af/at PoE or a Micro USB adapter (DC 5V) . The OC400 uses dual redundant internal power supplies .
- Silent Operation: Most models feature a fanless design for silent 24/7 operation. The larger OC400 includes a fan .
- Data Backup: Built-in USB ports (USB 2.0 on OC200/OC220; USB 3.0 on OC300/OC400) support automatic configuration backups .
Intelligent Monitoring & Maintenance
- Real-Time Insights: The dashboard provides instant visibility into network status, traffic distribution, and a real-time topology view for quick troubleshooting .
- Wi-Fi Heatmap Simulator: Plan your wireless deployment by simulating AP coverage on a floor plan before installation .
- Batch & Remote Management: Perform batch configuration, multi-site management, and remote firmware updates without manually configuring each device .
- Zero-Touch Provisioning: Simplify deployments by pre-configuring devices remotely, reducing the need for on-site IT experts .
Connectivity & Hardware Specs
- OC200: 2× 10/100 Mbps Ethernet ports, 1× USB 2.0 port .
- OC220: Upgraded to 2× Gigabit Ethernet ports and a Quad-Core CPU with 2 GB DDR4 RAM, offering 2.6× faster startup than the OC200 .
- OC300: 2× Gigabit Ethernet ports, 1× USB 3.0 port .
- OC400: 2× 10G SFP+ slots, 4× Gigabit RJ45 ports, 2× USB 3.0 ports, and a console port .
