The TP-Link AX3000 Dual Band Gigabit Wi-Fi 6 Router - ARCHER AX53 is a powerful Wi-Fi 6 (802.11ax) dual-band gigabit router designed to handle high-performance networking needs. Ideal for streaming, gaming, and smart home environments, it delivers blazing speeds up to 3 Gbps and offers technologies like MU-MIMO, OFDMA, and Beamforming to support multiple devices with minimal latency.
This model combines next-gen wireless with wired gigabit ports and supports comprehensive network management tools, VPN capabilities, and robust security protocols.
Hardware Specifications
- Model Variants: Commonly branded as Archer AX55 or AX50 (AX3000 class)
- Wireless Standards: IEEE 802.11ax/ac/n/a (5 GHz), IEEE 802.11ax/n/b/g (2.4 GHz)
- Wi-Fi Speed:
- 5 GHz: Up to 2402 Mbps (Wi-Fi 6 with HE160 support)
- 2.4 GHz: Up to 574 Mbps
- Combined: Approx. 3000 Mbps
- Antenna Setup:
- 4 fixed high-gain external antennas
- Beamforming supported for signal optimization
- Processor:
- Dual-core CPU
- RAM: Approx. 256 MB to 512 MB depending on model
- Storage: Typically 128 MB Flash
- Ports:
- 1 × Gigabit WAN port
- 4 × Gigabit LAN ports
- 1 × USB 3.0 port (varies by model)
- Power Supply: 12V ⎓ 2A (adapter included)
Wireless & Software Features
- Wi-Fi 6 Enhancements:
- OFDMA for simultaneous data streams
- MU-MIMO for multi-device performance
- Target Wake Time (TWT) for power efficiency
- Smart Features:
- Smart Connect (auto band assignment)
- Airtime Fairness
- DFS support for less congested channels
- Security:
- WPA3, WPA2-PSK, WPA-PSK encryption
- SPI Firewall, Access Control, IP & MAC binding
- VPN Support:
- OpenVPN, PPTP, and L2TP VPN server/client modes
- Mesh Capability:
- OneMesh™ supported for seamless whole-home coverage
- Parental Controls & QoS:
- Custom profiles, time scheduling, and content filters
- Device-based QoS (manual or automatic)
- Guest Network:
- Separate guest access on both 2.4 GHz and 5 GHz
- Cloud Services & App:
- TP-Link Tether app for mobile management
- Remote management via cloud with TP-Link ID
- OTA firmware updates
Environmental & Physical
- Dimensions: Approx. 260 × 135 × 40 mm
- Operating Temperature: 0°C to 40°C
- Storage Temperature: -40°C to 70°C
- Operating Humidity: 10%–90% non-condensing
- Mounting: Desktop or wall-mount
Short Key Features
- Dual-band Wi-Fi 6 speeds up to 3000 Mbps
- MU-MIMO + OFDMA for efficient multi-device support
- 4 high-gain antennas with beamforming
- 1× USB 3.0 port for file/media sharing
- Full VPN server/client support
- OneMesh™ and Smart Connect enabled
- App-based cloud control and parental management
- Robust WPA3 wireless security
