TP-DCDC-2448GD-HP A high-power Gigabit DC-DC converter with a PoE inserter stepping up to 56V. TP-DCDC- 2448GD-HP(18-36VDC in, 56VDC 35W out) | MDT Kenya | MDTRETAIL
TP-DCDC-2448GD-HP A high-power Gigabit DC-DC converter with a PoE
KSh 20,920(KSh 24,267 Incl VAT)
High-Power DC-DC Converter with PoE Inserter: Steps up 18–36VDC input to regulated 56VDC output with integrated Gigabit PoE injection for powering remote network devices -1-3
IEEE 802.3af/at Compliant: Delivers up to 35W of PoE power output, suitable for high-power wireless access points, IP cameras, IP phones, and PoE lighting applications -1-2
Dual Power Inputs for Redundancy: Features one common (-) and two (+) inputs, allowing connection of two power sources (e.g., primary and backup) for increased reliability in critical applications -1-8
Integrated Gigabit PoE Inserter: Accepts data-in via shielded RJ45 jack and provides data-out along with PoE power on the output jack; supplies power on Ethernet pins 4,5 (V+) and 7,8 (V-) -1-3
Comprehensive Protection Circuitry: Equipped with surge, short circuit, over current, and reverse/over voltage protection for safe and reliable operation in demanding environments -1-2
Wide Operating Temperature Range: Operates reliably from -30°C to 60°C, suitable for vehicle, industrial, and outdoor deployments -2-4
Compact Chassis Mount Design: Measures 124.5 x 76.2 x 38.1mm and weighs approximately 134g (4.7oz), maximizing available installation space -2-4
Vehicle and Battery System Ready: Ideal for 24V battery systems and vehicle applications, providing efficient PoE power from DC sources without requiring AC infrastructure -1-8
