Posiflex DT-208-B Mini POS Terminal

The Posiflex DT-208-B is a compact, fanless POS terminal designed for space-constrained retail and hospitality environments. Featuring an 8-inch non-touch display, AMD LX700 processor, 512MB RAM, and 40GB IDE HDD, this model combines reliability and efficiency for entry-level point-of-sale and customer interaction systems. It comes equipped with a 40-key programmable keyboard (LINCE) and supports multiple operating systems including WEPOS, POSReady, and Linux.

---

Detailed Specifications

Display & Design

• Display Size: 8-inch LCD
• Resolution: 800 × 600 (SVGA)
• Touchscreen: Non-touch display
• Aspect Ratio: 4:3
• Display Type: TFT LCD
• Design: Compact, fanless structure for silent and continuous operation
• Color: Black

Performance & Hardware

• Processor: AMD LX700, 433MHz, 433 FSB
• Memory: 512MB DDR RAM
• Storage: 40GB IDE HDD
• Graphics: Integrated with shared memory
• Cooling System: Fanless, ideal for dusty or noise-sensitive environments

Operating System Compatibility

• Supported OS:
  • WEPOS (Windows Embedded for Point of Service)
  • Windows POSReady
  • Linux

Input & Control

• Keyboard: 40-key LINCE programmable POS keyboard
  • Fully programmable for custom functions and macros
  • Supports key mapping for specific POS applications

Connectivity & Expansion

• I/O Interfaces:
  • Serial Ports (RS-232)
  • USB Ports
  • Parallel Port
  • PS/2 for keyboard/mouse
  • VGA output for external display (optional)
  • LAN (Ethernet) port

Physical & Environmental

• Construction: Durable industrial-grade casing
• Cooling: Passive (fanless) thermal management
• Operating Temperature: 0°C – 40°C
• Storage Temperature: -20°C – 60°C
• Humidity: 20% – 80% RH (non-condensing)

Power & Efficiency

• Power Supply: External power adaptor
• Energy Efficiency: Low power consumption optimized for continuous use

Compatibility & Use Cases

• POS Software Support: Compatible with standard POS software for Windows or Linux environments
• Typical Applications:
  • Retail cash register systems
  • Restaurant ordering terminals
  • Kiosk control systems
  • Back-office or warehouse data terminals

---

Key Features

• 8-inch non-touch fanless POS terminal
• AMD LX700 433MHz processor with 512MB memory
• 40GB IDE HDD for reliable offline data storage
• 40-key programmable LINCE keyboard for custom POS operations
• Supports WEPOS, POSReady, and Linux OS
• Silent fanless design ideal for 24/7 operation
• Compact form factor suitable for limited counter space

---
