Dual-Technology Detection: Combines a PIR sensor with a microwave module. An alarm is only triggered when both technologies detect movement, significantly reducing false alarms caused by temperature changes, sunlight, or small animals .
Coverage: Provides a volumetric detection area of 12m x 12m with an 85° wide angle, utilizing 78 detection zones .
Digital Quad Zone Logic: The PIR uses four sensing elements with digital signal processing to distinguish human movement from false alarm sources, contributing to better pet tolerance and environmental immunity .
Microwave Area Shaping: The microwave sensitivity and range are adjustable (LONG/SHORT), allowing you to shape the detection area to avoid false triggers from moving objects outside the protected zone (like curtains or fans) .
Advanced Sealed Optics: The lens design is sealed to prevent insects from reaching the sensor surface and causing false triggers .
Temperature Compensation: Automatically adjusts PIR sensitivity based on ambient temperature to maintain stable detection performance in warm environments where body heat contrast is lower .
Tough MW Module: The microwave component is designed for durability and consistent performance .
Included Bracket: Comes with a multi-angle mounting bracket for flexible installation on walls or in corners. The recommended mounting height is 1.5 to 2.4 meters .
Standards: Complies with EN50131-2-4 (the European standard for dual-technology detectors) and is rated Grade 2 .
Power: Operates on 9.5 to 16 VDC with a current draw of approximately 8–11 mA at 12 VDC .
Outputs: Includes a normally closed (N.C.) alarm output (24 VDC, 0.2 A max) and a tamper switch.
