KSh 50,580(KSh 58,673 Incl VAT)
Device Type: 22U Floor Standing Network / Server Cabinet (19" Rack)
Model / SKU: 22U-NC-S80-22U
Brand: Office Point
Rack Capacity: 22U (22 Rack Units); Internal usable installation height: approximately 980 mm (38.5 inches)
External Dimensions: 800 mm (Width) × 1000 mm (Depth); Height: Approximately 1200 mm (varies by manufacturer)
Rack Standard: 19-inch rack-mount rails (front and rear, adjustable)
Material: Heavy-duty steel construction (typically SPCC cold-rolled steel with powder coating); Frame thickness: ~1.2 mm; Mounting rails: ~2.0 mm
Front Door: Lockable (tempered glass or perforated metal, model dependent)
Rear Door: Lockable perforated or solid metal door
Side Panels: Removable and lockable side panels for secure yet convenient side access
Ventilation: Vent slots on doors/panels; supports optional fan trays at top; four high-speed top fans for active extraction (optional); perforated rear door for passive exhaust
Cable Management: Cable entry points (top and bottom) for structured routing; vertical cable management channels on both sides of the mounting rails (due to 800mm width)
Load Capacity: Designed for multiple rack devices; typical static load capacity for 22U cabinets ranges from 400 kg to 800 kg (refer to official datasheet for specific rating)
Colour: Typically black / dark grey (RAL9005 or similar)
Mounting Type: Floor standing; heavy-duty castors for mobility during setup; adjustable leveling feet for stable, vibration-free positioning
Security Features: Lockable front and rear doors; lockable removable side panels for controlled physical access
Key Features: Optimized for Deep Servers (1000mm depth accommodates enterprise servers with room for cable management and airflow); Superior Cable Management (800mm width provides vertical cable channels); Dual-Access Security (lockable front and rear doors); Heavy-Duty Mobility (castors + leveling feet); Passive & Active Cooling Options
Key Specs: Office Point 22U-NC-S80-22U 22U Floor Standing Network Server Cabinet, 800×1000mm, 19" Standard Rack Rails, Heavy-Duty Steel Construction, Lockable Front & Rear Doors, Removable Lockable Side Panels, Top & Bottom Cable Entry, Vertical Cable Management Channels, Castors + Leveling Feet, Static Load Capacity up to 800 kg, Black
Usage: Server Rooms, Data Rooms, Network Closets, Telecommunication Rooms, Security & Surveillance Control Rooms, Enterprise Edge Environments, and Small to Medium IT Infrastructure Deployments
