The
MikroTik RB750UPr2 hEX PoE lite is a compact and affordable wired router designed for small networks that require both connectivity and power distribution. It features a 650 MHz CPU, 64 MB of RAM, and five Fast Ethernet ports, four of which support
passive PoE out, allowing you to power other MikroTik or compatible devices directly from the router. With a
USB 2.0 port, it supports 3G/4G modems, external storage, or UPS monitoring. The device runs
RouterOS with a Level 4 license, enabling advanced features like VPN, firewall, bandwidth control, and routing protocols. Housed in a plastic case with
fanless, silent cooling, and bundled with a
24V 2.5A power supply, the hEX PoE lite is a practical solution for powering and managing small office or home networks efficiently.
Compact. Powerful. PoE-Ready.
π§ Key Features at a Glance
- CPU: 650 MHz QCA9531
- Memory: 64 MB RAM
- Storage: 16 MB Flash
- 5 x 10/100 Mbps Ethernet Ports
- PoE Out on Ports 2β5 (Passive PoE)
- USB 2.0 Port for 3G/4G modem, storage, or UPS monitoring
- RouterOS L4 License β Full feature routing capabilities
- Plastic Enclosure β Lightweight and durable
- Includes Power Supply Unit (PSU) β 24V 2.5A DC
βοΈ Hardware Specifications
| Specification |
Details |
| CPU |
QCA9531 @ 650 MHz |
| RAM |
64 MB DDR2 |
| Ethernet Ports |
5 x 10/100 Mbps (RJ45) |
| PoE Out Ports |
Ports 2, 3, 4, 5 (Passive PoE) |
| USB Port |
1 x USB 2.0 |
| Power Input |
8V β 30V DC (barrel or PoE in on port 1) |
| Power Output |
Up to 1A total on PoE out (shared) |
| Power Consumption |
~3W (without PoE out) |
| Dimensions |
113 x 89 x 28 mm |
| Case Type |
Plastic |
| Cooling |
Passive (silent operation) |
| Operating Temp |
-20Β°C to +70Β°C |
π‘ Software Features β RouterOS Level 4
β Static & Dynamic Routing (RIP, OSPF)
β Firewall & NAT
β DHCP Server/Client
β VPN Support (PPTP, L2TP, SSTP, IPsec)
β VLANs, Bridges, Queues
β Web Proxy & Bandwidth Control
β Monitoring Tools (Torch, Ping, Packet Sniffer)
π Power Over Ethernet (PoE) Output
- Voltage: Same as input (8β30V DC)
- Passive PoE Only: Compatible with MikroTik and other passive PoE devices
- Total Output Current: Up to 1A shared across ports 2β5
π§° Ideal For
- Small Office/Home Office (SOHO) networks
- IP camera or access point deployments
- Simple LANs with PoE-powered devices
- RouterOS learners and lab setups
π¦ Package Includes
- hEX PoE lite Router (RB750UPr2)
- 24V 2.5A Power Adapter
- Quick Start Guide
π Why Choose the hEX PoE lite?
β Compact, quiet, and energy-efficient
β Powers up to 4 other devices via PoE
β Full routing power with MikroTik RouterOS
β Affordable yet highly capable
