KIOXIA EXCERIA PLUS G3 INTERNAL SSD - LSD10Z002TG8

Device Type: Internal Solid State Drive (SSD)
Part Number/SKU: LSD10Z002TG8
Brand: KIOXIA (EXCERIA PLUS G3 Series)
Storage Capacity: 2 TB
Form Factor: M.2 Type 2280-S4-M (Single-Sided)
Interface: PCIe® Gen4 x4 (64 GT/s)
Protocol: NVMe™ 1.4
Flash Memory: KIOXIA BiCS FLASH™ TLC
Controller: Phison PS5021-E21 (4-channel, DRAM-less)
Performance (2TB Model):

• Max Sequential Read: Up to 5,000 MB/s
• Max Sequential Write: Up to 3,900 MB/s
• Max Random Read: Up to 680,000 IOPS
• Max Random Write: Up to 950,000 IOPS

Endurance & Reliability:

• TBW (Total Bytes Written): 1,200 TB
• MTTF: 1.5 Million Hours
• Warranty: 5-Year Limited Warranty

Physical & Environmental:

• Dimensions (L × W × H): 80.15 × 22.15 × 2.63 mm
• Weight: 7.4 g (Typical)
• Operating Temperature: 0°C (Ta) to 85°C (Tc)
• Storage Temperature: -40°C to 85°C
• Shock Resistance: 1,000 G / 0.5 ms half sine wave
• Vibration: 20 G Peak, 10–2,000 Hz
• Certification: RoHS Compliant
• Management Software: KIOXIA SSD Utility

Key Specs: KIOXIA EXCERIA PLUS G3 2TB (LSD10Z002TG8), M.2 2280 PCIe Gen4 x4 NVMe 1.4 SSD, BiCS FLASH TLC, Phison PS5021-E21 DRAM-less Controller, Up to 5,000MB/s Read / 3,900MB/s Write, 680K/950K IOPS, 1,200 TBW, 1.5M Hours MTTF, Single-Sided, 80.15 × 22.15 × 2.63 mm, 7.4g, 5-Year Warranty
Usage: Mainstream Desktop & Laptop Storage Upgrades, Gaming & Video Editing, OS Boot Drive, General Data Storage & Backup
