KSh 6,880(KSh 7,981 Incl VAT)
Device Type: Active Infrared (IR) Beam Detector / Photoelectric Perimeter Sensor (60m Outdoor)
Brand/Model: Generic — 60m IR Beam (common models: Optex AX-200TF, Takex PB-60TX, ABUS LS2060/LS2030)
Video Output: N/A (Intrusion detection device; relay output, not a video signal)
Data Ports: Alarm Relay Output (NC/NO dry contact) + Tamper Output (NC); Terminal Block Wiring (Power + Relay)
Detection & Performance:
Detection Method: Infrared beam interruption (dual synchronized beams; alarm triggers only when both beams are broken simultaneously)
Outdoor Detection Range: 60 m (200 ft)
Indoor Detection Range: Typically 120 m (400 ft) (double the outdoor rating)
Max Beam Arrival Distance: Up to 530 m (1,740 ft) on Optex AX-200 series
Interruption Period: Selectable 50 / 100 / 250 / 500 ms (4 steps)
Beam Channels/Frequencies: 4 selectable channels (prevents cross-talk between stacked units)
Light Immunity: Up to 50,000 lux sunlight immunity (auto-gain control)
Alignment: Visual (LED) and audible (sound check) alignment indicator
Electrical & Power:
Operating Voltage: 10.5–28 V DC (Optex AX-200) or 10–30 V DC (ABUS/Takex) — varies by model
Current Consumption: Approx. 37–65 mA
Alarm Output: Relay contact NC/NO, 28 V DC 0.2 A max (Optex); COM/NC/NO (ABUS)
Tamper Output: NC contact on both transmitter and receiver
Physical & Environmental:
Protection Rating: IP55 (ABUS, Takex) or IP65 (Optex AX-200) — verify on unit
Operating Temperature: −35°C to +60°C (Optex); −20°C to +60°C (some battery models); max +55°C (ABUS)
Dimensions (W×H×D): Approx. 170 × 65 × 69.5 mm (Optex) or 173 × 74 × 72 mm (ABUS)
Weight: Approx. 700–750 g per unit
Housing: UV-resistant ABS plastic with anti-frost / drip-proof design
Mounting: Wall or pole mount (brackets typically included)
Key Specs: 60m Outdoor Active IR Beam Detector, Dual Synchronized Beams, 60m Outdoor / 120m Indoor Range, Selectable 50–500ms Interruption Period, 4 Selectable Channels, 50,000 lux Sunlight Immunity, NC/NO Alarm + Tamper Relay Outputs, 10.5–30 V DC, IP55/IP65, −35 to +60°C, Visual/Audible Alignment, Anti-Frost Design
Usage: Perimeter Intrusion Detection for Residential & Commercial Properties, Fence-Line & Wall-Top Detection, Gate & Driveway Security, Balcony & Boundary Protection, Beam Stacking for Tall Perimeters (Multiple Beams), Integration with Alarm Panels & Access Control Systems
