Device Type: FBI-Certified Optical Fingerprint Reader (PIV Single Finger Capture Device)
Video Output: N/A
Data Ports: 1× USB 2.0 Hi-Speed / USB 1.1 Full-Speed (Type-A)
Fingerprint Sensor & Imaging:
Sensor Model: SecuGen SDU04P (optical, contact type)
Image Resolution: 508 DPI (native)
Image Size: 258 × 336 pixels
Platen Size: 14.6 mm × 17.9 mm
Effective Sensing Area: 12.9 mm × 16.8 mm
Grayscale: 256 levels (8-bit)
Certifications & Compliance:
FBI Certified: PIV, FIPS 201, Mobile ID FAP 10 Compliant (meets FBI NGI Image Quality Specifications)
Biometric Standards: INCITS 378, ISO/IEC 19794-2, ISO/IEC 19794-4, NIST MINEX, WSQ
Safety/EMC: FCC, CE, KC, RoHS, WHQL
Performance & Features:
Smart Capture Speed: 0.2 – 0.8 seconds (self-adjusting for dry, wet, scarred, or aged fingers)
Auto-On™: Automatic finger detection (when used with SecuGen SDKs)
Security: Latent print rejection (ignores prior prints left on sensor), template encryption (proprietary format), device recognition
Sensor Durability: Scratch-, impact-, vibration-, and electrostatic shock-resistant
Power & Physical:
Power Supply: 5 V DC (via USB)
Current Consumption: 150 mA (max.)
Cable Length: 1500 mm
Dimensions (with stand): 53 × 73 × 84 mm
Dimensions (without stand): 27 × 40 × 73 mm
Weight: 165 g (with stand) / 100 g (without stand)
Operating Temperature: −20°C to +65°C
Operating Humidity: ≤90% RH (non-condensing)
Key Specs: SecuGen Hamster IV (HSDU04P), FBI-Certified PIV/FIPS 201/Mobile ID FAP 10, 508 DPI Optical Sensor, 258×336 px Image, Smart Capture (0.2–0.8s), Auto-On Finger Detection, Latent Print Rejection, USB 2.0, 1500mm Cable, 165g with Stand
Usage: PIV/FIPS 201 Enrollment & Verification, Government & Enterprise Identity Authentication, Access Control & Time Attendance, Mobile ID & Law Enforcement Field Enrollment, Multi-Factor Authentication (MFA), Biometric Application Development (SDK available)
