Device Type: Outdoor Central Loose Tube Fiber Optic Cable (Armored, Unitube)
Model: GYXTW 24B1.3-OS2 (24-Core Single-Mode, 9.0mm, Black)
Video Output: N/A
Data Ports: N/A (unterminated fiber; requires splicing or field-installable connectors)
Optical & Fiber Specifications:- Fiber Count: 24 Cores
- Fiber Type: OS2 / G.652D (B1.3) Single-Mode (9/125 µm)
- Attenuation: ≤0.36 dB/km @ 1310nm; ≤0.22 dB/km @ 1550nm
- Wavelength: 1310nm / 1550nm
Cable Construction & Mechanical:- Structure: Central loose tube (jelly-filled) with corrugated steel tape armoring and two parallel steel wire strength members
- Outer Sheath: PE (Polyethylene), Black, UV-resistant
- Nominal Diameter: 9.0 mm (Note: Standard 24-core GYXTW is often listed at 8.0mm–8.8mm; 9.0mm is a valid compact/standard variant)
- Tensile Strength (Long/Short Term): Typically 600 N / 1,500 N (some 24-core variants rated 1,000/3,000 N)
- Crush Resistance (Long/Short Term): Typically 300 N / 1,000 N per 100mm
- Bending Radius (Static/Dynamic): 10D / 20D
- Operating Temperature: −40°C to +70°C
Key Specs: GYXTW 24-Core Single-Mode (OS2/G.652D), 9.0mm Black PE Jacket, Central Loose Tube, Steel Tape Armor, 2x Steel Wire Strength Members, 600/1500N Tensile (Typical), 300/1000N Crush, −40 to +70°C
Usage: Outdoor Duct or Aerial Backbone Cabling, Long-Distance Communication, Interoffice Links, Campus LAN, FTTH Feeder Lines
