Device Type: Edge Data Center / Smart Mini Data Center (Single Cabinet)
Brand/Model: Huawei FusionModule500 (5.0)
Power System: 6kVA or 10kVA UPS, Single Phase (220/230/240V AC, 50/60Hz), Power Factor 1.0, Efficiency up to 96%
Cooling: Integrated Cooling Unit (3.5kW capacity, direct expansion air-cooled), Hot/Cold Aisle Containment
Monitoring: Remote Web UI Access, Unified Multi-Site Management, 10-inch Local Touchscreen (Optional), SMS/Email Alarms, Mobile O&M App Support
Data Ports: rPDU Outputs (IEC C13 optional), Sensor Ports for T/H, Smoke, Water Leak, Door Status
Battery: Lead-Acid or Lithium (SmartLi), Backup Time 15min–4h (Configurable)
Dimensions (W x H x D): 600mm x 2000mm x 1100mm (Standard Cabinet)
Protection: IP20, Integrated Fire Suppression Module (Optional), Automatic Door Opening for Emergency Heat Dissipation
Key Specs: Huawei FusionModule500, Edge Data Center, Single Cabinet "One Cabinet One DC", 6kVA/10kVA UPS, Integrated Cooling 3.5kW, Remote Web Monitoring, Hot/Cold Aisle, Fire Suppression Optional, IP20, 2-Hour Rapid Deployment
Usage: Edge Computing Sites, Branch Offices, Retail, Finance, Education, Healthcare, Small IT Rooms
