Device Type: Outdoor Multimode Fiber Optic Cable (Central Loose Tube)
Brand/Model: Generic — 12-Core OM2, Black PE Jacket (no single standardized manufacturer model; verify drum label)
Video Output: N/A
Data Ports: N/A (unterminated fiber; requires splicing or field-installable connectors)
Fiber Count: 12 cores
Fiber Type: OM2 Multimode (50/125 µm)
Cable Construction: Central loose tube, gel-filled, with water-blocking yarns/tape
Armoring/Strength: Corrugated steel tape (CST) armoring; some variants include two parallel steel wires for additional tensile strength
Outer Jacket: PE (Polyethylene), Black, UV-resistant
Nominal Diameter: 6.5 mm – 9.6 mm (varies by armoring and strength-member construction)
Nominal Weight: 37 kg/km – 110 kg/km (varies by construction)
Tensile Strength (Long/Short Term): 600 N / 1,800 N (typical for lightweight central loose tube); higher ratings (up to 3,000 N) for armored variants
Crush Resistance (Long/Short Term): 1,000 N / 2,000 N per 100 mm (typical)
Bending Radius (Static/Dynamic): 10D / 20D (typical)
Operating Temperature: −40°C to +70°C
Key Specs: 12-Core OM2 Multimode Outdoor Cable, 50/125µm, Black PE Jacket, Central Loose Tube, Steel Tape Armoring (CST), UV-Resistant, 600/1800N Tensile (Typical), −40°C to +70°C
Usage: Outdoor Backbone Cabling (Aerial, Duct, or Direct Burial), Campus LAN, FTTH/FTTB Feeder Lines, Telecom Access Networks, Industrial Environments
